4X4D Two-dimensional Silicon Array Detectors

Product information "4X4D Two-dimensional Silicon Array Detectors"

4x4 Array Detector; 810, 850 nm Band Optimized; Active Area 1,0, 1.96 mm2; Responsivity 0.35 to 0.4 A/W; Capacitance 35, 75 pF; Package Ceramic LCC

OSI Optoelectronics’ 4X4D series comprise 4 by 4 arrays of super blue enhanced photodetectors. Two models are available: PIN-4X4D silicon array detectors feature an active area of 1.96 mm2 and a peak responsivity wavelength of 850 nm, while UDT-4X4D silicon array detectors with an active area of 1.0 mm2 show peak responsivity at 810 nm.

OSI Optoelectronics’ proprietary design provides virtually complete isolation between all of the 16 elements. The standard LCC package allows easy integration into your surface mount applications. Numerous applications include ratio and scattering measurements, as well as Position Sensing. For custom packages, special electro-optic requirements, or to order these parts in die form, please contact AMS Technologies.

Key Features:

  • 4x4 Array Detector
  • Active Area: 1.0x1.0 mm (UDT-4X4D), 1.4x1.4 mm (PIN-4X4D)
  • Peak Responsivity Wavelength: 810 (UDT-4X4D), 850 nm (PIN-4X4D)
  • Very Fast Response
  • Extremely Low Cross-talk
  • Surface Mount Design
  • Package: Ceramic LCC

Applications: Ratio and Scattering Measurements; Position Sensing

Manufacturer "OSI Optoelectronics"
