Laser Safety Goggles

Plastic; Filter Type: 0337; 10% VLT; 530-607 nm; Purple Made of special plastic, the laser safety eyewear ONTOR is the perfect solution to wear over prescription glasses. The black/grey ONTOR frame offers a large field of vision as well as lateral impact protection. The temples of the laser safety goggles can be adjusted in length and inclination. A removable soft and rubberized face foam improves the wearing comfort. The model 000-K0337-ONTO-52 features the laser safety filter #0337 by PROTECT-Laserschutz, making it suitable in particular for dye lasers. The filter 0337 covers additional wavelengths as well. The laser safety filter consists of a pink polycarbonate and offers a visual light transmission (VLT) of more than 10 % and a minor filter thickness. The laser safety filter is CE certified in accordance with the requirements of EN 207. Key Features: Frame Colour Black/Grey Filter Thickness approx. 2.0 mm Optical Class 1 Areas of Refractive Power: 0 dpt   Protection Levels: Wavelength (nm) Certified protection levels according to EN 207  530 – 535  DIR LB2 (OD 2+) >535 – 565 DIR LB3 (OD 3+) >565 – 569 DIR LB4 (OD 4+) >569 – 572  D LB4 + IR LB5 (OD 5+) >572 – 580 D LB4 + IR LB6 (OD 6+) >580 – 600 D LB4 + IR LB7 (OD 7+) >600 – 607 DIR LB3 (OD 3+)   PF CE Please note the wavelengths of your laser system and the corresponding protection levels. Calculate the required protection levels for the wavelengths carefully and compare them with the information in the protection level description above. This is the only way to ensure that the glasses can be used without risk.   Scope of Delivery: 1 Laser Safety Eyewear with black/grey ONTOR Frame Case Microfiber Cloth Instruction for Use Spectacle Cord

Material Synthetic, Tissue, Aluminium Composite, Steel Sheets, Special Laser Protective; Thickness 0.8-100 mm; Max. Power Density 100 W/ m2-25 MW/m2 for 100 s Our broad portfolio of PROTECT-Laserschutz laser safety curtains and laser safety cabins for different applications allows you to find the appropriate large area laser protection solution for your laser. All safety materials are tested and certified according to EN 12254. In order to provide the maximum level of protection for employees it is necessary to choose the appropriate safety material for protection of large areas against laser radiation. Several laser parameters such as the wavelength, the laser power and the mode of operation are considered for protection level calculations. Please carefully calculate the required safety levels for your laser - for advice how to choose the right large area laser protection solution for your application, get in touch with the AMS Technologies laser safety experts now. isoPROTECT-Budget, isoPROTECT-Budget LP, isoPROTECT-Budget-Extra, and isoPROTECT-Budget Superior laser safety curtains for low-power applications protect against scattered radiation as well as direct radiation. Due to in-house production, all dimensions are available (as far as technically possible). Made from synthetic material with thicknesses of approximately 0.8, 0.85, 1.6 and 2.8 mm, these laser safety curtains allow maximum power densities of 100 W/m2 to 2.5 MW/m2 for 100 s. In addition, individual wishes such as velcro, hem and eyelet tape are possible on request. Standard colour is Carbon/Carbon and for larger quantities a choice from a variety of other colours is available. isoPROTECT Service, a mobile large area laser safety barrier, is made from isoPROTECT-Budget black synthetic material with 0.8 mm thickness. The standard version consists of three individual panels (2 x 1 m each) that can be connected by Velcro. These panels are arbitrarily extendable, can be easily mounted based on aluminium frames and the transport in the included storage bag is comfortable. The isoPROTECT High Tech laser safety curtain provides highest possible protection levels for applications with the danger of direct radiation. Due to in-house production, all dimensions are available (as far as technically possible). If larger surfaces are needed, this curtain can be easily expanded thanks to velcro tape. Made from tissue with a thickness of approximately 2.0 mm, this laser safety curtain allows maximum power densities of 1 to 25 MW/m2 for 100 s. Coating is available in black and white. As one of the leading manufacturers of laser protection cabins, PROTECT-Laserschutz is familiar with the customers’ specific requirements of laser protection cabins. PROMETHEUS and HERCULES laser safety cabins are designed in accordance to individual specifications and customized to the user's specific laser system. Get in touch with the AMS Technologies laser safety experts now to discuss your customized laser protection cabin solution. While PROMETHEUS laser cabins made of Aluminium Composite material with 4 mm thickness allow maximum power densities of 10 to 250 MW/m2 for 100 s, HERCULES laser safety cabins made of steel sheets and special laser protective material with 100 mm thickness allow maximum power densities of 10 to 2500 MW/m2 for 100 s. Experienced and reliable installation partners can promptly install PROTECT-Laserschutz protection cabins on-site. On request, we are glad to perform a risk analysis at your company, so that your cabin can be used in conformity with EN 60825-4 and be classified as laser class 1. Certified according to EN ISO 13849-1, the LSK10 laser safety control system for entrance doors to cabins allow active controlling of laser applications by interlock contacts, by power supply or by beam dumps. There are various input types for integration of mechanical/magnetic door contacts, warning lights, emergency stops, laser safety roller blinds and curtains. Key Features: Laser Safety Curtain Material: Synthetic, Tissue Laser Safety Curtain Thickness: 0.8 to 2.8 mm Laser Safety Curtain Maximum Power Densities: 100 W/m2 to 25 MW/m2 for 100 s, Depending on Laser Wavelength Laser Safety Cabin Material: Aluminium Composite, Steel Sheets and Special Laser Protective Laser Safety Cabin Thickness: 4, 100 mm Laser Safety Cabin Maximum Power Densities: 10 to 2500 MW/m2 for 100 s, Depending on Laser Wavelength Applications: Protection of Large Areas Against Potentially Dangerous Radiation Emitted by Common Laser Types

Window Material Special Plastics or Glass; Wavelength Protection Ranges 193-12000 nm; Max. Dimensions 0.210x0.297-1.5x30 m Our broad portfolio of PROTECT-Laserschutz laser safety windows for different applications allows you to find the laser safety filter for your application. Choose from 24 different plastic filter models and six different glass filter models, covering the safety requirements for applications with common laser types listed below. The operation of laser systems in many areas of industry, medicine, research and a growing number of further applications is constantly increasing, while the lasers get more powerful and more comprehensive in their settings. Accordingly, the requirements and challenges of laser safety windows are increasing. The selection of the right laser safety window is essential to ensure the protection of the employees. A large number of different laser parameters, such as wavelength, power and pulse mode, are included in the calculation. Please carefully determine the required safety levels for your laser to select a suitable laser safety window. All PROTECT-Laserschutz laser safety windows are certified and tested in accordance with the valid standards according to international and European optical and laser standards (EN 207 / EN 208). For advice how to choose the right laser safety window for your application, get in touch with the AMS Technologies laser safety experts now. Common Laser Types: Laser Type Wavelengths Alexandrite Laser 755 nm Argon Laser 515 nm Blue Laser 450 - 480 nm CO + CO2 Laser 5 - 12 µm Diode Laser 630 - 660 nm Diode Laser 1470 nm Diode Laser 940 - 980 nm Diode Laser 808 nm Diode Laser 630 - 660 nm Diode-Nd:YAG Laser 800 - 1064 nm Diode-Nd:YAG Laser 900 - 1400 nm Dye Laser 585 - 595 nm Dye Yellow Laser 577 nm Er:YAG Laser 2780 - 2940 nm Erbium Glass Laser 1540 nm Excimer Laser 193 nm Fibre Laser 1060 - 1080 nm Harmonic Nd:YAG Laser 532 nm Harmonic Nd:YAG Laser 355 nm Harmonic Nd:YAG Laser 266 nm HeNe Laser 633 nm Ho:YAG Laser 2100 nm KTP Laser 532 nm Nd:YAG Laser 1320 nm Nd:YAG Laser 1064 nm Nd:YAG + Harmonic Laser 266 + 355 + 532 + 1064 nm Nd:YAG Q-switched Laser 532 + 1064 nm RGB Laser 450 + 532 + 650 nm Ruby Laser 694 nm Supercontinuum Laser 350 - 2600 nm Thulium Laser 1480 + 1940 nm Ti:Saphir Laser 800 nm UV Laser 248 nm Yb:YAG/Disc Laser 1030 nm Yellow-Green Laser 561 nm   Key Features: Laser Safety Filter Material: Special Plastics or Glass Wavelength Protection Ranges: 193 to 12000 nm Certified and Tested Against Optical and Laser Standards EN 207 / EN 208 Maximum Dimensions Special Plastic Windows: 810 x 950 mm to 1.5 x 30 m Maximum Dimensions Glass Windows: 210 x 297 mm Application: Protection Against Potentially Dangerous Radiation Emitted by Common Laser Types

Lead Equivalent of Glasses 0.50, 0.75 mm Pb; Classic or Sportive Frame Designs; Some Models Also Available With Single, Bifocal, Progressive Lenses Okay, these goggles do not exactly provide “Laser Safety” ;-), but they also protect the eyes from radiation: Our broad portfolio of PROTECT-Laserschutz X-Ray protection goggles for different applications include a range of classic or sportive frame designs. X-Ray protection goggles are also available with single, bifocal and progressive lenses according to your correctional values. The selection of the X-ray safety eyewear is essential to ensure the protection of employees and/or patients. Below you find an overview of available PROTECT-Laserschutz X-Ray protection goggles. The AMS Technologies safety experts are looking forward to assisting you by choosing the right safety equipment – get in touch now to discuss your requirements. Available X-Ray Protection Googles: X-Ray Eyewear XR540 "Berlin" Sportive Wraparound-Design; Matt Black Surface; Indirect Ventilation; Lead Equivalent of Glasses: 0.75 mm Pb; Available With Your Correctional Values on Request X-Ray Eyewear XR550 "Rom" Sportive Wraparound-Design; Lenses Wrap Around the Face; Bicolored Frame Design; Lead Equivalent of Glasses: 0.75 mm Pb; Available With Your Correctional Values on Request X-Ray Eyewear XR560 "Prag" Elegant High-quality Design; Extra-wide Lenses; Wraparound Technology; Low Weight; Lead Equivalent of Glasses: 0.50 mm Pb X-Ray Eyewear XR580 "Oslo" Sportive Wraparound-Design; Classic Black Glossy Surface; Lead Equivalent of Glasses: 0.75 mm Pb; Available With Your Correctional Values on Request X-Ray Eyewear XR610 "Paris" Classic Brown Overspec; Adjustable Temples; Lead Equivalent of Glasses: 0.75 mm Pb; Additional Lateral Protection Through Glasses on the Sides With 0,5 mm Pb Equivalent X-Ray Eyewear XR620 "London” Modern Overspec Designed to Fit Over Corrective Spectacles; Flexible Side Arms; Close Fitting Frame; Lead Equivalent of Glasses: 0.75 mm Pb   Key Features: Classic or Sportive Frame Designs Lead Equivalent of Glasses: 0.50, 0.75 mm Pb Some Models Also Available With Single, Bifocal, Progressive Lenses Application: Protection of Human Eyes Against Potentially Dangerous X-Ray Radiation
