Large Area Laser Protection

Product number: SW11482

Manufacturer: PROTECT-Laserschutz

Product information "Large Area Laser Protection"

Material Synthetic, Tissue, Aluminium Composite, Steel Sheets, Special Laser Protective; Thickness 0.8-100 mm; Max. Power Density 100 W/ m²-25 MW/m² for 100 s

Our broad portfolio of PROTECT-Laserschutz laser safety curtains and laser safety cabins for different applications allows you to find the appropriate large area laser protection solution for your laser. All safety materials are tested and certified according to EN 12254.

In order to provide the maximum level of protection for employees it is necessary to choose the appropriate safety material for protection of large areas against laser radiation. Several laser parameters such as the wavelength, the laser power and the mode of operation are considered for protection level calculations. Please carefully calculate the required safety levels for your laser - for advice how to choose the right large area laser protection solution for your application, get in touch with the AMS Technologies laser safety experts now.

isoPROTECT-Budget, isoPROTECT-Budget LP, isoPROTECT-Budget-Extra, and isoPROTECT-Budget Superior laser safety curtains for low-power applications protect against scattered radiation as well as direct radiation. Due to in-house production, all dimensions are available (as far as technically possible). Made from synthetic material with thicknesses of approximately 0.8, 0.85, 1.6 and 2.8 mm, these laser safety curtains allow maximum power densities of 100 W/m² to 2.5 MW/m² for 100 s. In addition, individual wishes such as velcro, hem and eyelet tape are possible on request. Standard colour is Carbon/Carbon and for larger quantities a choice from a variety of other colours is available.

isoPROTECT Service, a mobile large area laser safety barrier, is made from isoPROTECT-Budget black synthetic material with 0.8 mm thickness. The standard version consists of three individual panels (2 x 1 m each) that can be connected by Velcro. These panels are arbitrarily extendable, can be easily mounted based on aluminium frames and the transport in the included storage bag is comfortable.

The isoPROTECT High Tech laser safety curtain provides highest possible protection levels for applications with the danger of direct radiation. Due to in-house production, all dimensions are available (as far as technically possible). If larger surfaces are needed, this curtain can be easily expanded thanks to velcro tape. Made from tissue with a thickness of approximately 2.0 mm, this laser safety curtain allows maximum power densities of 1 to 25 MW/m² for 100 s. Coating is available in black and white.

As one of the leading manufacturers of laser protection cabins, PROTECT-Laserschutz is familiar with the customers’ specific requirements of laser protection cabins. PROMETHEUS and HERCULES laser safety cabins are designed in accordance to individual specifications and customized to the user's specific laser system. Get in touch with the AMS Technologies laser safety experts now to discuss your customized laser protection cabin solution. While PROMETHEUS laser cabins made of Aluminium Composite material with 4 mm thickness allow maximum power densities of 10 to 250 MW/m² for 100 s, HERCULES laser safety cabins made of steel sheets and special laser protective material with 100 mm thickness allow maximum power densities of 10 to 2500 MW/m² for 100 s.

Experienced and reliable installation partners can promptly install PROTECT-Laserschutz protection cabins on-site. On request, we are glad to perform a risk analysis at your company, so that your cabin can be used in conformity with EN 60825-4 and be classified as laser class 1.

Certified according to EN ISO 13849-1, the LSK10 laser safety control system for entrance doors to cabins allow active controlling of laser applications by interlock contacts, by power supply or by beam dumps. There are various input types for integration of mechanical/magnetic door contacts, warning lights, emergency stops, laser safety roller blinds and curtains.

Key Features:

Laser Safety Curtain Material: Synthetic, Tissue
Laser Safety Curtain Thickness: 0.8 to 2.8 mm
Laser Safety Curtain Maximum Power Densities: 100 W/m² to 25 MW/m² for 100 s, Depending on Laser Wavelength
Laser Safety Cabin Material: Aluminium Composite, Steel Sheets and Special Laser Protective
Laser Safety Cabin Thickness: 4, 100 mm
Laser Safety Cabin Maximum Power Densities: 10 to 2500 MW/m² for 100 s, Depending on Laser Wavelength

Applications: Protection of Large Areas Against Potentially Dangerous Radiation Emitted by Common Laser Types

Manufacturer "PROTECT-Laserschutz"

PROTECT Laserschutz manufactures laser safety products such as laser safety eyewear, laser saftey windows, laser safety clothing. The company is specialized on the sectors medical science, industry, research and development.
