ThermoCube II 200-500 Thermoelectric Recirculating Chillers
REQUEST PRICING AND AVAILABILITY
- Get your individual quote.
- Technical compatibility review included.
- Volume discounts available.
No obligation. Direct access to our engineering team.
Product information "ThermoCube II 200-500 Thermoelectric Recirculating Chillers"
Cooling Capacity 200 to 500 W @+20 °C; Process Fluid Flow Rate 1.5 to 3.0 lpm @ 30 psig; 1/4” John Guest or Other Fittings; 9 Diaphragm, Gear or Centrifugal Pump Options; Wetted Materials Al, Cu or Stainless Steel Cold Plate
The ThermoCube II 200–500 Thermoelectric Chillers from Solid State Cooling Systems are engineered for precision temperature control in laboratory, analytical, and OEM environments. These advanced benchtop chillers offer configurable cooling capacities ranging from 200 to 500 watts, delivering exceptional thermal stability and repeatability. Built on robust thermoelectric technology, the ThermoCube II eliminates the need for compressors and refrigerants, offering a quiet, low-maintenance solution for applications where uptime and accuracy are essential.
Compact yet powerful, the ThermoCube II measures 11 x 13 x 13 inches (28 x 32 x 33 cm) and weighs just 28 lbs (12.7 kg), making it ideal for installations with limited space. The standard operating range of 5°C to 50°C can be extended to -5°C or up to 65°C with optional configurations. A digital PID controller ensures ±0.05°C temperature stability, while the modular design allows users to tailor the unit to specific process requirements.
Key Features
- Highly Configurable Design: Four base models with options for extended temperature ranges, flow meters, leak detectors, and alternate fluids.
- Thermoelectric Cooling: Solid-state technology ensures quiet operation, low vibration, and long service life without refrigerants.
- Advanced Control & Communication: RS232, RS485, Ethernet, TTL, and keypad interface for seamless integration into automated systems.
- Flexible Pump & Fitting Options: Six pump types (diaphragm, centrifugal, gear) and nine fitting choices (John Guest, CPC, APC, Swagelok, NPT).
- Compact Footprint: Fits easily on lab benches or within OEM enclosures; universal power input (100–240 VAC, 50/60 Hz).
- Quiet Operation: Below 50 dBA at 50% load and under 63 dBA at full load.
- Safety & Compliance: Alarms for temperature, fluid level, and system faults; UL, CE, CAN/CSA, and RoHS certified.
Applications
- Analytical Instruments: Spectroscopy, chromatography, and mass spectrometry systems requiring stable thermal environments.
- Laser & Photonics Systems: Diode lasers and optical components needing precise temperature regulation.
- Life Sciences & Biotech: Microfluidics, sample preparation, and temperature-sensitive assays.
- OEM Integration: Medical, diagnostic, and scientific equipment with space and control constraints.
- Imaging Systems: CCD and CMOS sensors used in low-light or high-resolution imaging applications.
What's Next?
If your application demands precise, reliable, and customizable thermal control, the ThermoCube II 200–500 Thermoelectric Chillers offer a proven solution. With over 34,000 units shipped globally, this platform is trusted by researchers and engineers for its performance and adaptability.
Contact our sales team today to discuss your requirements, request a quote, or explore configuration options tailored to your system.
