905 nm; Spectral Width 5 nm; Min. Optical Power 20-350 W; Typ. Pulse Width 10, 30 ns; Emitter Area 200x10, 200x480 µm; No. of Diodes 1, 5 OSI LaserDiode’s LHCVN Series of 905 nm hybrid laser diodes for pulsed operations incorporates a pulsed laser firing circuit into the same package as the laser diode. The hybridization of the driver permits much narrower pulse widths and faster rise times at lower voltage requirements than discrete laser drivers. The LHCVN series is compatible with all OSI LaserDiode standard MOCVD laser diodes and can be optimally driven utilizing commercially available MOSFET drivers. The hermetic TO5 package and increased efficiency is ideal when space and weight are of primary concern. Key Features: High Efficiency High Peak Power Emission Peak Emission Wavelength: 905 nm Spectral Width (FWHM): 5 nm Beam Spread (FWHM): 9° x 25° Low Voltage Operation (100 V Maximum) Number of Diodes: 1, 5 Minimum Optical Power: 20 to 350 W Pulse Width: 10, 30 ns (Typical) Emitter Area: 200 x 10 µm, 200 x 480 µm Rise/Fall Times: 2 ns (Typical) Operating Voltage: 40, 100 V (Typical) RoHS Compliant Operating Temperature: 0 °C to +75 °C Dimensions: 9.19 mm Dia. x 10.67 mm Length Applications: Rangefinders, Ceilometers; Weapons Simulation; Surveying; LIDAR

PM Fiber; 1550 nm; 8/125 µm Fiber; FC/APC; 0.4 mm Jacket; 2.5 µm Spot Diameter; 14 µm Working Distance; 2 m Length; AR Coating; 10 mm Stripped Length

Sensor Size 4 x 4 - 100 x 80 mm; 350-1100 nm; Power Range 1-2,500 µW; Position Resolution 0.1-100 µm; Position Accuracy 25-1,000 µm; Interface Analog, USB 2.0, MobileLasers propagating through space have a perfect line trajectory. Using this quality, combined with a position sensor capable of measuring perpendicularly to the propagation direction, Duma Optronics’ comprehensive series of beam positioners yields a perfect system for straightness and alignment. Many applications such as machine straightness measurement, alignment of optical systems, vibration and quality control are enabled by combining the system with the powerful computing capability of today. Optical beam position measurements can be done by a variety of sensor heads, including CCD or miniature and large-area PSD. Duma Optronics offers a variety of sensor head sizes to accommodate numerous application needs. Position sensing provides measurements of optical beam location on a detector surface, and also provides absolute power measurements. Duma Optronics’ series of laser beam positioners are measuring accurately down to fractions of a micron, wherein lower resolution allows measurements over wide areas up to 100 mm. This series includes various detector types such as lateral effect, centrally perforated four-quadrant in 4 x 4 mm up to 100 mm size, and CCD. SpotOn Analog: A complete solution for fast and extremely accurate beam positioning. The system measures both optical beam position and power. Download datasheetSpotOn Mobile: High-accuracy compact beam positioning system with Nexus7 PC tablet included. Download datasheetLaserOn: Compact visible laser diode (635 nm) with built-in screws for fine beam direction adjustment. Completing usage for positioning. Download datasheetSpotOn LA: Large aperture beam positioning system for applications exceeding 100 mm of beam positioning area. Download datasheetSpotOn USB 2.0: A portable, fast and accurate optical beam positioning system (down to 0.1 µm) featuring a USB 2.0 interface. Download datasheetKey Features: Complete Line of Laser Beam Positioning Various Detector Types: Lateral Effect, Centrally Perforated Four-quadrant, CCD Simultaneous Operation of Several Detectors Fast Acquisition up to 60 kHz Calibrated Lasers for Alignment Reference Applications: Machine Straightness Measurement; Alignment of Optical Systems; Vibration Measurement; Quality Control

30 to 4,000 pF; 1.8 to 36 kV Vacuum capacitors for high voltage and high frequency applications offer long, maintenance-free service life and the ability to withstand transients that destroy other types of capacitors. Vacuum assures oxidation-free surfaces and a dielectric that is self-healing when subject to transient over-voltage conditions. This series of variable vacuum capacitors offers capacitances of 30 to 4,000 pF, withstanding working voltages at 50/60 Hz in the range of 1.8 to 36 kV. In addition to this working voltage, a value for AC test voltage is quoted in this series’ product specifications. The maximum operating current for vacuum capacitors is limited by temperature rise and working voltage. A current vs. frequency chart is provided for each capacitor. If none of our standard catalog models meet your needs, our supplier`s engineers are happy to work with you to design a custom solution that meets your specific requirements. Capacitance Tolerance: For this series of variable capacitors, the low-end capacity will be equal to or less than minimum rating. The capacitance change is substantially uniform with rotation, and there are no capacitance reversals. Capacitance is within ±10% of the nominal value of the curves shown in the data sheet (capacity vs. turns), in the linear portion of this curve. Torque/Direct Pull: In variable capacitors, the linear sliding motion of the moving electrode assembly is converted to rotary tuning via a threaded shaft. The torque values given in the tables are the maximum torque needed to reach minimum capacitance when rotated with a standard lead screw; the torque required to tune away from minimum may be less than half this value. For most variable capacitors, direct pull tuning is an available option to rotary tuning. Maximum required direct pull force values are also given in the tables. Capacitance range end-stops are built into every variable capacitor. It is recommended that the user install their own external stops to prevent damage from gear-reduction drives. Mechanical Life: The mechanical life of variable capacitors is related to length of stroke, speed of operation, bellows material and total number of cycles. Extensive mechanical life tests have been run, operating units for complete cycles from maximum to minimum and back to maximum capacity covering 95% of the full stroke of the movable plates. Capacitors with a large bellows and a short stroke will have the greatest life expectancy under cycling operation. Our most recent variable capacitor models are rated for >2 million cycles, ideal for the semiconductor processing industry. Testing Standards: All capacitors are factory tested for dielectric strength on a 100% basis prior to shipment, using a low current, high potential source at 60 Hz voltage. Upon customer request, certified test reports will be made available. Key Features: High Voltage Rating High RF Current Ratings for normal convection cooling in ambient temperature of +25 °C (unless otherwise specified) Maximum Allowable Temperature: +125 °C Low Losses Self-healing High Altitude Operation Wide Tuning Ranges Mounting Position: Any Rotation to Increase Capacity: Counterclockwise Typical Applications: Broadcast Radio Transmitters; Semiconductor Manufacturing Equipment; Plasma Generating Equipment; Industrial Dielectric Heating Equipment; Power Switching and Interrupting; Avionic and Mobile Radio Systems; Radar Antenna Switching; MRI and NMR; High Voltage Capacitor Banks
