pco.edge 10 bi CLHS

0.36-5 MP; Pixel Size 2.2x2.2-6.0x6.0 µm; Sensor Size 1/3”-1/2” Diagonal; Colour or B/W; 3-310 fps; Resolution 8-12 bit; USB 2.0; Buffered; Progressive Scan; Dynamic Range >55-70 dB; Board-level or Enclosed Mightex’s B-Series USB 2.0 CMOS cameras with frame buffers are optimized for machine-vision applications, and they can also be used for a wide variety of other applications such as digital microscopy and medical imaging, where quality, ease of use, and cost-effectiveness are crucial. B-Series cameras are available as colour or B/W versions, with resolutions from Wide VGA (WVGA, 752x480) up to 5 MP (2592x1944) and 8, 10 or 12 bit, and they can be ordered as “naked” board-level device or pre-mounted in an enclosure. Monochrome cameras often exhibit a 20% higher spatial resolution than their colour counterparts because no pixel interpolation is necessary. Without a Bayer colour filter on the sensor, monochrome cameras are also more sensitive than colour sensors, especially in near IR and UV regions. Mightex’s B-Series cameras feature built-in frame buffers, global shutter (Wide VGA versions), external trigger-in, strobe-out, and a powerful camera engine that supports multiple cameras. The frame rate can be as high as 60 fps in full resolution and up to 600 fps using ROI mode (depending on colour or B/W and sensor resolution). In addition, a user-friendly GUI based application software and an SDK are provided for custom software development. A DirectShow driver and a TWAIN driver are included (except for 5 MP B/W versions), and a USB command set protocol is provided for non-Windows based applications. A Linux driver is also either included (5 MP and Wide VGA B/W versions) or available upon request. Available models are: BCN-C050-U/BCN-C050-US: 5 MP, colour, lens mount C/CS, board-level BCE-C050-U/BCE-C050-US: 5 MP, colour, lens mount C/CS, enclosed BCN-B050-U/BTN-B050-U: 5 MP, B/W, 8/12 bit, lens mount C or CS, board-level BCE-B050-U/BTE-B050-U: 5 MP, B/W, 8/12 bit, lens mount C or CS, enclosed BCN-C030-U/BCN-C030-US: 3 MP, colour, lens mount C/CS, board-level BCE-C030-U/BCE-C030-US: 3 MP, colour, lens mount C/CS, enclosed BCN-B013-U/BCN-B013-US: 1.3 MP, B/W, 8 bit, lens mount C/CS, board-level BCE-B013-U/BCE-B013-US: 1.3 MP, B/W, 8 bit, lens mount C/CS, enclosed BTN-B013-U/BTN-B013-US: 1.3 MP, B/W, 10 bit, lens mount C/CS, board-level BTE-B013-U/BTE-B013-US: 1.3 MP, B/W, 10 bit, lens mount C/CS, enclosed BCN-CG04-U/BCN-CG04-US: WVGA, colour, lens mount C/CS, board-level BCE-CG04-U/BCE-CG04-US: WVGA, colour, lens mount C/CS, enclosed BCN-BG04-U/BCN-BG04-US: WVGA, B/W, 8 bit, lens mount C/CS, board-level BCE-BG04-U/BCE-BG04-US: WVGA, B/W, 8 bit, lens mount C/CS, enclosed BTN-BG04-U/BTN-BG04-US: WVGA, B/W, 10 bit, lens mount C/CS, board-level BTE-BG04-U/BTE-BG04-US: WVGA, B/W, 10 bit, lens mount C/CS, enclosed Note: Board-level cameras are designed for OEM applications, when a system-level enclosure is usually provided. In order to avoid electro-static discharge (ESD) related damages, workforce handling a board-level camera should be properly grounded. ESD related damages are considered as mishandling and are not covered by product warranty. For lab use, it is strongly recommended to choose an enclosed camera instead of a board-level one. Key Features: Colour or Black&White (B/W, Monochrome) Board-level or Enclosed Versions Available Ultra-compact Active Imaging Pixels: 0.36 to 5 MP, 752x480 to 2592x1944 Pixel Size: 2.2 x 2.2 to 6.0 x 6.0 µm Sensor Size (Diagonal): 1/3” to 1/2” Dynamic Range: >55 to 70 dB Buffered, 32 MByte On-board Memory (3 to 23 Frames at Full Resolution, Depending on Sensor) 8, 10 or 12 bit Gray Level Progressive Scanning System Frame Rate: 3 to 310 fps True Global Shutter (Wide VGA Versions) Supports Simultaneous Image Capturing From Multiple Cameras 4-pin GPIOs Arbitrary ROI Supported (Wide VGA Versions) Interface: High-speed USB 2.0 (480 Mbit/s), No Need for External Power Supply Digital Output, No Need for Frame Grabber Custom Programmable With SDK Provided DirectShow & TWAIN Drivers Linux Driver (5 MP and Wide VGA B/W Versions) USB Command Set Protocol for Non-Windows-based Applications External and Software Trigger Strobe Output for External Flash Precise Frame Rate Setting (Wide VGA Versions) ROI (Not Wide VGA Versions) and Pixel Skipping/Binning OEM Versions Available Applications: Machine Vision and Stereo Vision; Medical Imaging; Semiconductor Equipment; Test Instruments; High-quality ID Photo Capture; Document Scanners; Digital Microscopy; Web Camera and Security Video

1.3 MP; Pixel Size 3.75x3.75 µm; Sensor Size 6.26x5.01 mm; Colour or B/W; 20-66 fps; Resolution 8, 12 bit; USB 2.0; Buffered; Progressive Scan; Board-level or Enclosed; Global Shutter Mightex’s C-Series compact USB 2.0 1.3 MP 1/3” CCD cameras with frame buffers are optimized for machine-vision applications, and they can be also used for a wide variety of applications (such as industrial inspections, digital microscopy and medical imaging) which require good quality cameras that are easy to use and cost-effective. C-Series compact 1/3” CCD cameras are available as colour or B/W versions, with 1.3 MP (1280x960) resolution and 8 or 12 bit, and can be ordered as “naked” board-level device or pre-mounted in an enclosure. Monochrome cameras often exhibit a 20% higher spatial resolution than their colour counterparts because no pixel interpolation is necessary. Without a Bayer colour filter on the sensor, monochrome cameras are also more sensitive than colour sensors, especially in near IR and UV regions. C-Series 1/3” CCD cameras have built-in frame buffers, global shutter, external trigger-in, strobe-out, and a powerful camera engine that supports multiple cameras. The frame rate can be as high as 20 fps in full resolution and up to 84 fps using ROI mode. A user-friendly GUI based application software and an SDK are provided for custom software development. In addition, a DirectShow driver and a TWAIN driver are available to easily link the cameras with users’ applications. A USB command set protocol and a Linux driver are also provided for non-Windows based applications. Available models are: CGN-C013-U: colour, board-level CGE-C013-U: colour, enclosed CGN-B013-U: B/W, board-level CGE-B013-U: B/W, enclosed Note: Board-level cameras are designed for OEM applications, when a system-level enclosure is usually provided. In order to avoid electro-static discharge (ESD) related damages, workforce handling a board-level camera should be properly grounded. ESD related damages are considered as mishandling and are not covered by product warranty. For lab use, it is strongly recommended to choose an enclosed camera instead of a board-level one. Key Features: Colour or Black&White (B/W, Monochrome) Built-in Frame Buffer 32 MByte (24 Frames at Full Resolution) Support Simultaneous Image Capturing From Multiple Cameras Higher Sensitivity Than CMOS Cameras B/W Cameras Feature Higher Sensitivity (Especially in Near IR and UV) Board-level or Enclosed Versions Available Ultra-compact Active Imaging Pixels: 1.3 MP, 1280x960 Pixel Size: 3.75 x 3.75 µm Sensor Size: 6.26 x 5.01 mm (1/3” Diagonal) 8 or 12 bit Progressive Scanning System Frame Rate: 20 to 66 fps Global Shutter 4-pin GPIOs Interface: High-speed USB 2.0 (480 Mbit/s), No Need for External Power Supply Digital Output, No Need for Frame Grabber Full-featured SDK DirectShow & TWAIN Drivers Linux Driver Available USB Command Set for Non-Windows-based Applications External and Software Trigger Strobe Output for External Flash ROI and Pixel Skipping OEM Versions Available Applications: Digital Microscopy; Machine Vision; Medical Imaging; Semiconductor Equipment; Test Instruments; Document Scanners; 2D Barcode Readers; Web Camera and Security Video; High-quality ID Photos

1.4 MP; Pixel Size 4.65x4.65 µm; Sensor Size 7.60x6.20 mm; Colour or B/W; 15-49 fps; Resolution 8, 12 bit; USB 2.0; Buffered; Progressive Scan; Board-level or Enclosed; Global Shutter Mightex C-Series USB 2.0 1.4 MP 1/2” CCD cameras with frame buffers have high sensitivity and low noise, and they are optimized for a wide variety of applications, including machine-vision applications, digital microscopy and medical imaging, where quality, ease of use, and cost-effectiveness are crucial. C-Series high-sensitivity 1/2” CCD cameras are available as colour or B/W versions, with 1.4 MP (1392x1040) resolution and 8 or 12 bit, and can be ordered as “naked” board-level device or pre-mounted in an enclosure. Monochrome cameras often exhibit a 20% higher spatial resolution than their colour counterparts because no pixel interpolation is necessary. Since there is no Bayer colour filter on the sensor, monochrome cameras are more sensitive than colour sensors, especially in near IR and UV regions. C-Series 1/2” CCD cameras have built-in frame buffers, global shutter, external trigger-in, strobe-out, and a powerful camera engine that supports multiple cameras. The frame rate can be as high as 15 fps in full resolution and up to 80 fps using ROI mode. In addition, a user-friendly GUI based application software and an SDK are provided for custom software development. A USB command set protocol is also provided for non-Windows based applications. Available models are: CCN-C013-U: colour, board-level CCE-C013-U: colour, enclosed CCN-B013-U: B/W, board-level CCE-B013-U: B/W, enclosed Note: Board-level cameras are designed for OEM applications, when a system-level enclosure is usually provided. In order to avoid electro-static discharge (ESD) related damages, workforce handling a board-level camera should be properly grounded. ESD related damages are considered as mishandling and are not covered by product warranty. For lab use, it is strongly recommended to choose an enclosed camera instead of a board-level one. Key Features: Colour or Black&White (B/W, Monochrome) Built-in Frame Buffer 32 MByte (24 Frames (Colour), 8 Frames (B/W) at Full Resolution) Support Simultaneous Image Capturing From Multiple Cameras Higher Sensitivity Than CMOS Cameras B/W Cameras Feature Higher Sensitivity (Especially in Near IR and UV) Board-level or Enclosed Versions Available Ultra-compact Active Imaging Pixels: 1.4 MP, 1392x1040 Pixel Size: 4.65 x 4.65 µm Sensor Size: 7.60 x 6.20 mm (1/2” Diagonal) 8 or 12 bit Progressive Scanning System Frame Rate: 15 to 49 fps Global Shutter 4-pin GPIOs Interface: High-speed USB 2.0 (480 Mbit/s), No Need for External Power Supply Digital Output, No Need for Frame Grabber Full-featured SDK DirectShow & TWAIN Drivers Linux Driver Available USB Command Set for Non-Windows-based Applications External and Software Trigger Strobe Output for External Flash ROI and Pixel Skipping OEM Versions Available Applications: Digital Microscopy; Machine Vision; Medical Imaging; Semiconductor Equipment; Test Instruments; Document Scanners; 2D Barcode Readers; Web Camera and Security Video; High-quality ID Photos

1.4 MP; Pixel Size 6.45x6.45 µm; Sensor Size 2/3” Diagonal; Colour or B/W; 15-49 fps; Resolution 8, 12 bit; USB 2.0; Buffered; Progressive Scan; Board-level or Enclosed; Global Shutter Mightex’s C-Series USB 2.0 1.4 MP 2/3” CCD cameras with frame buffers are optimized for machine-vision applications, and they can be also used for a wide variety of applications such as digital microscopy and medical imaging, where quality, ease of use, and cost-effectiveness are crucial. C-Series high-sensitivity 2/3” CCD cameras are available as colour or B/W versions, with 1.4 MP (1392x1040) resolution and 8 or 12 bit, and can be ordered as “naked” board-level device or pre-mounted in an enclosure. Monochrome cameras often exhibit a 20% higher spatial resolution than their colour counterparts because no pixel interpolation is necessary. Without a Bayer colour filter on the sensor, monochrome cameras are also more sensitive than colour sensors, especially in near IR and UV regions. C-Series 2/3” CCD cameras have built-in frame buffers, global shutter, external trigger-in, strobe-out, and a powerful camera engine that supports multiple cameras. The frame rate can be as high as 15 fps in full resolution and up to 80 fps using ROI mode. In addition, a user-friendly GUI based application software and an SDK are provided for custom software development. A USB command set protocol is also provided for non-Windows based applications. Available models are: CXN-C013-U: colour, board-level CXE-C013-U: colour, enclosed CXN-B013-U: B/W, board-level CXE-B013-U: B/W, enclosed Note: Board-level cameras are designed for OEM applications, when a system-level enclosure is usually provided. In order to avoid electro-static discharge (ESD) related damages, workforce handling a board-level camera should be properly grounded. ESD related damages are considered as mishandling and are not covered by product warranty. For lab use, it is strongly recommended to choose an enclosed camera instead of a board-level one. Key Features: Colour or Black&White (B/W, Monochrome) Built-in Frame Buffer (8 Frames at Full Resolution) Support Multi-Camera Applications B/W Cameras Feature Higher Sensitivity (Especially in Near IR and UV) Board-level or Enclosed Versions Available Ultra-compact Active Imaging Pixels: 1.4 MP, 1392x1040 Pixel Size: 6.45 x 6.45 µm Sensor Size: 11.0 mm Diagonal (2/3”) 8 or 12 bit Progressive Scanning System Frame Rate: 15 to 49 fps Global Shutter 4-pin GPIOs Interface: High-speed USB 2.0 (480 Mbit/s), No Need for External Power Supply Digital Output, No Need for Frame Grabber Full-featured SDK Compatible With Windows 2000, XP, Vista, Windows 7 and 8 TWAIN Driver USB Protocol for Non-Windows-based Applications External and Software Trigger Strobe Output for External Flash ROI and Pixel Skipping/Binning OEM Versions Available Applications: Digital Microscopy; Machine Vision; Fluorescence Imaging; Medical Imaging; Semiconductor Equipment; Test Instruments; Document Scanners; 2D Barcode Readers; High-quality ID Photos; Security Camera; Astrophotography

Accessories for Mightex CMOS and CCD cameras include: M12 Lens Mounts: Stand-alone M12 lens mount for MCN- and BCN-Series cameras, IR-Cut filter not included. Part Number: ACC-CAM-M12 Stand-alone M12 lens mount for S-Series cameras, IR-Cut filter not included. Part Number: ACC-CAM-S-M12 Cables & Brackets: 183 cm long USB A-B cable. Part Number: ACC-USB-2M Extra-length (457 cm long) USB A-B cable; Part Number: ACC-USB-5M 183 cm long USB A-miniB cable; Part Number: ACC-USB-M2M 183 cm long USB A-miniB cable with locking screws, for S-Series enclosed cameras only. Part Number: ACC-USB-M2M-S Extra-length (457 cm long) USB A-miniB cable; Part Number: ACC-USB-M5M Mightex’s M-Series, B-Series, CCD (except CGx-Series) and USB3.0 camera trigger cable with an 8-pin DIN connector. For GPIOs and external triggers etc. 50 cm length. Part Number: ACC-CAM-DIN8 Mightex’s Con8 cable for S-Series and CGx-Series CCD cameras. For GPIOs and external triggers etc. 1 m length. Part Number: ACC-CAM-CON8 USB connector holding bracket for Mightex’s MCE-, BCE-, and SME-Series CMOS cameras. Part Number: ACC-CAM-BRKT Optical Filters: IR-cut filter. Dimensions: 18 mm in diameter, and 1 mm in thickness. Part Number: ACC-CAM-IRC Various IR-pass filters. Dimensions: 15(L) x 13(W) x 2(T) mm. Part Number ACC-CAM-IRPxxx Plain glass plates for Mightex’s cameras. Dimensions: 18 mm in diameter, and 1 mm in thickness. Part Number: ACC-CAM-PGP Please note that, while ACC-CAM-IRC and ACC-CAM-PGP can be drop-in replacement, ACC-CAM-IRPxxx will have to be glued to the camera using epoxy due to its 2 mm thickness. Camera Lens Mount Adapters: CS-mount to C-mount lens adapter. Part Number: ACC-CAM-CSC C-mount to M12x.5 adapter. Part Number: ACC-CAM-CM12 C-mount to 23 mm adapter (for microscope eyepiece tube). Part Number: ACC-CAM-C23 C-mount to 1.25″ adapter for cameras (for telescope 1.25″ eyepiece tube). Part Number: ACC-CAM-C1Q Stand-alone M12 lens mount for MCN- and BCN-Series cameras, IR-Cut filter not included. Part Number: ACC-CAM-M12 Stand-alone CS lens mount for MCN- and BCN-Series cameras, IR-Cut filter not included. Part Number: ACC-CAM-CS

Accessories for Mightex CCD line cameras include: F-mount lens adapter for TCN-1304-U line camera. Part Number: AC-LCM-F F-mount lens adapter for TCE-1024-U(F), TCE-1304-U, TCN-1209-U and TCE-1209-U line camera. Part Number: ACC-LCE-F Daughter-board/motherboard connection cable for TCN-1304-U line camera , 120mm long. Part Number: ACC-1304-120 Daughter-board/motherboard connection cable for TCN-1304-U line camera, 200mm long. Part Number: ACC-1304-200 Mechanical adapter for CCD Line Camera TCE-1024-U(F), TCE-1304-U, TCN-1209-U and TCE-1209-U, with C-type lens mount. Part Number: ACC-LCE-C Mechanical adapter for CCD Line Camera TCN-1304-U, with C-type lens mount. Part Number: ACC-LCM-C

1.3, 3 MP; Pixel Size 3.2x3.2, 5.2x5.2 µm; Sensor Size 6.66x5.32 mm; Colour or B/W; 8-600 fps; Resolution 8 bit; USB 2.0; Unbuffered; Progressive Scan; Dynamic Range 61, 68 dB; Board-level or Enclosed Mightex’s M-Series USB 2.0 CMOS cameras are designed for a wide variety of applications such as machine vision, digital microscopy and medical imaging, where quality, ease of use, and cost-effectiveness are crucial. With a USB2.0 interface and powerful PC software, the unbuffered M-Series cameras deliver excellent quality images, and the frame rate can be as high as 24 fps (8 fps for colour cameras) in full resolution and up to 600 fps using ROI mode. In addition, a user-friendly GUI based application software and an SDK are provided for custom software development. The cameras have 4-pin GPIOs and optional built-in LED drivers. A DirectShow driver and a TWAIN driver are also provided in order to easily link the cameras with users’ applications. M-Series cameras are available as 3 MP (2048x1536) colour or 1.3 MP (1280x1024) B/W versions and can be ordered as “naked” board-level device or pre-mounted in an enclosure. Monochrome cameras often exhibit a higher spatial resolution than their colour counterparts because no pixel interpolation is necessary. Without a Bayer colour filter on the sensor, monochrome cameras are also more sensitive than colour sensors, especially in infrared (IR). Available models are: MCN-B013-U/MCN-B013-US: B/W, lens mount C/CS, board-level, no built-in LED drivers GLN-B013-U/GLN-B013-US: B/W, lens mount C/CS, board-level, built-in LED drivers MCE-B013-U/MCE-B013-US: B/W, lens mount C/CS, enclosed, no built-in LED drivers MLE-B013-U/MLE-B013-US: B/W, lens mount C/CS, board-level, built-in LED drivers MCN-C030-U: colour, lens mount C or CS, board-level, no built-in LED drivers GLN-C030-U: colour, lens mount C or CS, board-level, built-in LED drivers MCE-C030-U: colour, lens mount C or CS, enclosed, no built-in LED drivers MLE-C030-U: colour, lens mount C or CS, enclosed, built-in LED drivers Note: Board-level cameras are designed for OEM applications, when a system-level enclosure is usually provided. In order to avoid electro-static discharge (ESD) related damages, workforce handling a board-level camera should be properly grounded. ESD related damages are considered as mishandling and are not covered by product warranty. For lab use, it is strongly recommended to choose an enclosed camera instead of a board-level one. Key Features: Colour or Black&White (B/W, Monochrome) B/W Cameras Feature Higher Resolution & Sensitivity (Especially in IR) and Low Noise Board-level or Enclosed Versions Available Unbuffered Built-in LED Drivers Active Imaging Pixels: 1.3 MP (B/W, 1280x1024), 3 MP (Colour, 2048x1536) Pixel Size: 3.2 x 3.2 µm (Colour), 5.2 x 5.2 µm (B/W) Sensor Size: 6.66 x 5.32 mm Dynamic Range: 61 dB (Colour), 68 dB (B/W) 8 bit Gray Level Progressive Scanning System Frame Rate: 8 to 600 fps 4-pin GPIOs Simpler Data Processing Interface: High-speed USB 2.0 (480 Mbit/s), No Need for External Power Supply Digital Output, No Need for Frame Grabber Custom Programmable With SDK Provided DirectShow & TWAIN Drivers External and Software Trigger Strobe Output for External Flash ROI and Pixel Skipping/Binning OEM Versions Available Applications: Digital Microscopy; Machine Vision; Medical Imaging; Semiconductor Equipment; Test Instruments; Document Scanners; 2D Barcode Readers; Web Camera and Security Video
