Accessories for Collimated LED Light Sources
Accessories for Mightex collimated LED light sources comprise dedicated focusing modules and interchangeable collimating lenses, lightguide, microscope and fiber-optic adapters, microscope illumination tubes, connector tubes, a thread converter, empty filter/optics holders, a lightguide holder for converting Type-B LCS into Type-B GCS as well as accessories for beam combiners like a push-pull adjustable mount, a 11 mm LCS adapter or connecting plates.
Six different ACC-LCS-F-xx focusing modules for collimated LED light sources are available, comprising modules for 11 to 48 mm clear-aperture collimated LED light sources with working distances from 5 to 100 mm. For details, please refer to the downloadable “Accessories for Collimated LED Light Sources Overview” and the downloadable installation drawings.
Eight ACC-LCS-C-xx(-B) additional interchangeable collimating lenses for collimated LED light sources are used to produce different beam sizes with the same LED light source base: Four models with clear apertures of 11, 22, 38 and 48 mm as well as four variants for Type-B light sources. For details, please refer to the downloadable “Accessories for Collimated LED Light Sources Overview”.
Four different LCS-LGA22-xxx lightguide adapters can be used to couple light from a 22-mm-diameter collimated LED light source into a lightguide. Variants for lightguides with ferrule diameters of 5, 6.35 (1/4”), 7 and 11.1 mm as well as a ferrule length of 15 mm or greater are available. For details, please refer to the downloadable “Accessories for Collimated LED Light Sources Overview” and the downloadable installation drawings.
Eight different ACC-BC25-xxx microscope adapters allow to connect LCS collimated LED light sources and beam combiners to microscopes. Single LCS light sources as well as LCS-BC25 beam combiners or WLS sources can be connected to microscopes like Leica DMI, Olympus (IX & BX, other), Zeiss Axioskop, Nikon Eclipse, Eclipse E200 and LV-UEPI/2/A. For details, please refer to the downloadable “Accessories for Collimated LED Light Sources Overview”.
A LCS-FPC-ADP-SMA fiber-optic adapter can be used to couple light from a LCS-Series collimated LED light source (22-mm aperture) into a fiber patchcord and accepts SMA connectorized fiber patchcords.
Three different ACC-BC25-MIT-xxx microscope illumination tubes allow to couple a beam combiner or LCS-Series collimated LED light source into the infinity optical path of microscopes. The lengths of these microsope illumination tubes are designed for one beam-combiner distance (up to two LCS sources) or two beam-combiner distances (up to four LCS sources). For details, please refer to the downloadable installation drawing.
Three different ACC-LCS-xxx connector tubes for LCS-Series collimated LED light sources are available, comprising a male-to-male C-mount connector with inner threads, a female-to-female C-mount connector with outer threads and a 15 mm extension tube for 22 mm clear-aperture LCS-Series light sources. For details, please refer to the downloadable “Accessories for Collimated LED Light Sources Overview”
An ACC-LCS-27C adapter is available for converting M27 thread to C-thread.
Two different empty filter/optics holders for 22 mm clear-aperture collimated LED light sources are available (ACC-LCS-H-22, ACC-LCS-EH). Both are excitation filter holders for 25.4 mm (1”) diameter filters with up to 5 mm thickness, with ACC-LCS-EH featuring a threaded output end to connect to Mightex LCS-LGA22-xxx lightguide adapters or ACC-BC25-xxx microscope adapters. For details, please refer to the downloadable “Accessories for Collimated LED Light Sources Overview” and the downloadable installation drawing.
Mightex’s GCS-LGH-B-0515 lightguide holder is used to replace the collimating lens on a Type-B LCS in order to convert it to a Type-B GCS. This holder is suitable for lightguides with a ferrule diameter of 5 mm (typical 3-mm-core lightguides) and a ferrule length of 15 mm or greater.
Mightex’s ACC-LCS-BC25-PPM push-pull mount for multi-wavelength beam combiners is user-adjustable.
Currently, Mightex’s multi-wavelength beam combiners can only be used to directly combine 22-mm-diameter collimated LED light sources. For 11-mm-diameter collimated LED light sources, an ACC-BC25-011 mechanical adapter can be used to attach the LED sources to the beam combiners, before the 11-mm-diameter collimated LED sources can be combined.
Three different ACC-BC25-CP-01/02/03 connecting plates are available to connect two or more multi-wavelength beam combiners together, with four screws included. For details, please refer to the downloadable “Accessories for Collimated LED Light Sources Overview” and the downloadable product overview.
