14100700 Cleaning Tools for Optics

Cartridge;OPTIPOP;Consumable

Multi Mode, Square Core; 190 to 2400 nm; Core Size 100 to 1000 µm; Coating Acrylate, Nylon, Polyimide; Numerical Aperture 0.22Fiberguide’s Anhydroguide™ (ASQR) and Superguide™ (SSQR) series of square silica core, doped round cladding multi mode optical fibers excel in specific applications where traditional circular core fibers with Gaussian outputs are not ideal. The uniform “top hat” intensity profile these fibers provide are the desired output profile when performing tasks such as welding, photolithography, and spectroscopy. Square core fibers with round claddings are also excellent candidates for use in the laser diode industry, where the square shape enables a more ideal coupling match with the diode source. Fiberguide offers pure silica square core fibers with a fluorine doped cladding (0.22 NA) in a wide range of core diameters from 100 μm to 1000 μm. While the ASQR series features a low hydroxyl ion concentration (low OH) and works in the visible to IR range, SSQR variants with high hydroxyl ion concentration are suitable for the UV to visible range. Options include Acrylate, Polyimide and Nylon coatings as well as anti-reflective coatings like standard thin film coatings or RARe Motheye nano-surfacing. This anti-reflective technology enhances fiber transmission performance and significantly increases the damage threshold for your application over a large wavelength range. Key Features: Homogenized Output Distribution Top Hat Beam Profile Greater Capture Area than Round Fibers for Square Inputs Step Index Multi Mode Fibers Square Silica Core / Doped Round Cladding Coatings: Acrylate, Nylon, Polyimide Core Sizes: 100 to 1000 µm Typical Clad/Core Ratio (RD Clad): 1.2 (Diagonal to Clad OD) Wavelengths: SSQR (High OH) 190 to 1250 nm, ASQR (Low OH) 300 to 2400 nm Numerical Aperture (NA): 0.22 ±0.02 100% Proof Test Using 4-Axis Bend Method Applications: Laser Materials Processing; Astronomical Spectroscopy; Non-circular Diode Beam Coupling; Photolithography

Polishing film;1.25mm/2.5mm diameter;Final

400 to 2200 nm; Return Loss ≥40 to ≥60 dB; Available Polarization Extinction Ratio >35; Fiber Type SM, Coating ≤400 µm OZ Optics’ FPC/HFPC/PFPC series of fiber polarization controllers allows to convert any input polarization to any desired output polarization. These devices combine the compact size and ease of use of standard bulk optics systems with low cost, low loss and low back reflection. FPC/HFPC/PFPC controllers work by applying pressure with an adjustable clamp. The pressure on the fiber causes a birefringence within the fiber core, causing the fiber to act as a fractional wave plate. Varying the pressure varies the delay between the fast and slow polarization components. The clamp is rotatable, allowing to change the direction in which the stress is applied. This allows any output polarization to be achieved. The process is simple and quick, output polarizations exceeding 30 dB can be routinely achieved in seconds. FPC/HFPC/PFPC fiber polarization controllers work with single mode (SM) fiber of any wavelength. For multi mode (MM) and polarization maintaining (PM) fiber, AMS Technologies offers OZ Optics’ FPR series of polarization rotators, controllers and analyzers. FPC/HFPC/PFPC fiber polarization controllers are offered in three versions. The FPC in-line polarization controllers can be inserted into a customer’s own single mode fiber. OZ Optics now provides this unit in a miniature size housing for applications where space is critical. FPC controllers can be used with any wavelength single mode fiber and is designed to work with 250 and 400 µm jacketed fibers. With the PFPC devices, pigtailed versions are also offered. PFPC versions are available with any size of cable or fiber and with your choice of connectors. Finally, HFPC connector receptacle style controllers are available, using a short section of fiber terminated with female receptacles. For further information, please contact the AMS Technologies optical fiber experts. Key Features: No Intrinsic Loss No Backreflection Compact Size, Miniature Housing Easy to Use Wavelength Insensitive Wavelength Range 400 to 2200 nm Applications: Single Mode (SM) to Polarization Maintaining (PM) Fiber Launching; Polarization Dependent Loss (PDL) Measurements; Launching into Polarization Sensitive Devices; Fiber Lasers; Fiber Interferometers; OCT Systems
