14100710 Cleaning Tools for Optics

Cost Effective; Magnification x400; Field of View 0.7 x 0.5 mm; Focus Manually, Auto; Light Source Coaxial, Stray Light; Output Interface USB 2.0 Data-Pixel’s D SCOPE PM benchtop fiber microscope for single-fiber connectors is dedicated to PANDA polarization maintaining (PM) fibers. It combines the high-quality inspection image of the D SCOPE microscope with low cost. The D SCOPE PM microscope is able to measure in real time the angular alignment of the stress elements relative to the connector key position. With Data-Pixel’s BLINK PM Aligner software, the D SCOPE PM microscope provides operators with an automated tool to control and measure PM fiber orientation inside connectors. D SCOPE PM microscopes are compatible with Data-Pixel’s SUPERVISOR software, a MES style software which is in charge of the execution, management and monitoring of the production in an assembly workshop for fiber optic connectors. Its role is to supervise machines and help operators with complete traceability of the manufacturing information. Key Features: Measures PANDA Style Fibers Magnification x 400 True Koehler Optical Design for Homogeneous Lighting Automated and Real-time Measurement Easy Calibration With BLINK PM Aligner High-speed USB 2.0 for Live Digital Image Field Stop Diaphragm Ergonomic Fine Focus Control USB-powered – No Outside Power Supply Needed Compatible With Desktop PC, Laptop, Tablet PC Applications: Measure the Angular Alignment of the Stress Elements in a PANDA PM Fiber Relative to the Connector Key Position in Real-time; Automated Control and Measurement of PM Fiber Orientation Inside Connectors
