5cc Syringe, threaded

One touch connecting! Excellence in liquid stable dispensing with high level of airtightness! This tube is used to carry the compressed air from the dispenser housing to the syringe.  Adapter material: Polyacetal (AT-100E: Made of Aluminium)  Tube material: Vinyl chloride (for S series dispensers: Polyurethane) O-ring material: fluororubber (nitrile rubber for 1mL type)

5cc Syringe clear, threaded, for use with pneumatic dispenser

Adapter Tube 5cc for pneumatic dispensing units

Cap with thread for syringes

This switch is used to trigger and stop dispensing with your foot. Since the shape of the metal bracket varies with the dispenser, select the switch design for the type of dispenser you are using.

Foot Switch for pneumatic dispensing units

Control System Electronic, Image Recognition; Number of Axes Controlled 3; Travel Range 80-500 mm; Operating Speed 1-500 mm/s; Repetitive Position Accuracy ±0.005 mm Mushashi Engineering’s IMAGEMASTER 350PC Smart series of desktop gate-type dispensing robots with camera alignment and laser Z follow features PC control image recognition and provides a fusion dispensing “core” technologies with Musashi Engineering’s desktop robot platform. With its automatic correction for individual differences in works and pallet array errors, the IMAGEMASTER 350 PC Smart series provides complete 3-D alignment, approximately 30% improvement in operation efficiency leading to significantly reduced labour time, yield improvement thanks to high-quality dispensing, as well as operability improvement and reduction in programming effort. This series’ new edge-detection function with support for various work shapes allows for adjustment of the position of work using image processing in a broader range of conditions, including works that could not be detected previously. Coordination with the dispenser is improved by the SynchroSpeed™ function, achieving a constant drawing width that is independent of robot speed. Thus, high-quality dispensing is implemented without the need for complicated adjustments. With its repetitive positioning accuracy of ±0.005 mm, the IMAGEMASTER 350PC Smart series offers high levels of dispensing quality for enhanced yield. Available with X- and Y-axis working areas from 200 to 500 mm, these dispensing robots are suitable for a variety of workspace environments. Musashi Engineering’s IMAGEMASTER 350PC Smart series allows fully automated, high- 3-axial dispensing – for example dispensing various optical adhesives in photonics applications. A broad portfolio of accessories is available for Musashi Engineering’s dispensers, ranging from high-precision, high-quality, highly reliable syringes & accessories to unique nozzles and needles that can handle any type of fluid and dispensing requirements as well as other accessories for dispensers. Specifications: Name 350PC Smart SM200ΩX 350PC Smart SM300ΩX 350PC Smart SM400ΩX 350PC Smart SM500ΩX Model 350PCS-SM200OMEGAX 350PCS-SM300OMEGAX 350PCS-SM400OMEGAX 350PCS-SM500OMEGAX Number of Controlled Axes 3 Axes Control Method PTP Control, Interpolation Control Travel Range X, Y-Axes 200 x 200 mm 300 x 300 mm 400 x 400 mm 500 x 500 mm Z-Axis 80 mm PTP Operation Speed Setting Range X, Y Axes 1 to 500 mm/s Z-Axis 1 to 400 mm/s Interpolation Operation Speed Setting Range X, Y Axes 0.1 to 500 mm/s Z-Axis  0.1 to 400 mm/s Repetitive Positioning Accuracy X/Y/Z ±0.005 mm Transportable Weight (*1) 20 kg Rated Power Supply 100 to 240 VAC, 50/60 Hz Power Consumption (*1) 250 W 300 W External Dimensions (*1) Width 465 mm 595 mm 695 mm 795 mm Depth 460 mm 570 mm 670 mm 770 mm Height 590 mm 590 mm 590 mm 590 mm Weight (*1) 47 kg 60 kg 79 kg 94 kg *1 This is a reference value and varies according to option configurations. Key Features: Support SynchroSpeed™ Function for Coordination With Dispenser Edge Detection Function Supporting Various Work Shapes Dispense Correction Function Syringe Setup Gap Measurement Data Retention Nozzle Cleaning and Test Shot Production Management Functions: Production Log, Process Monitoring Inspection Functions: Dimension Measurement, Dispense Path Trace, Map Generator, Simple Dispense Shape Judgment Other Functions: 3-D Alignment, Work Height Measurement, Nozzle Height Detection, Offset, Nozzle Gap Correction, Automatic Focus, Log Options: Leakage Protection Box, Field Network Unit, Teaching Pendant Set, External Operation Box, Work Bases, Holder Units, Nozzle Cleaner, Protection Cover, Signal Tower, Dispenser Connection Cable Fast and Easy Programming Complete 3D Alignment Also Available in Clean Room Edition CE Marking Certified, EU RoHS Compliant Applications: Fully Automated, High-precision and Fast Dispensing of Optical Adhesives, Solder, UV Adhesives, Threadlockers and Other Fluids
