TC10 LAB TEC Temperature Controllers

Benchtop or Chassis

DB 15+2 Cable Assembly The WCB406 cable mates with the Thermoelectric Output and Sensor connector on the rear panel of the TC5 LAB, TC10 LAB and TC15 LAB temperature control instruments. It is 3-feet long, 14-gauge on the power TEC pins, 22 AWG on the rest of the wires. Terminated with the 15+2 pin D-sub connector and 45° hood on one end, there are two other ends. One is twisted pair red & black 14-gauge wire for the thermoelectric connections. The other has four 22-gauge wires for thermistor and auxiliary sensor inputs.

Motor, pump, 1/2 hp, 115/230 VAC, 1 ph, 50/60 Hz, 4.3 gpm. The 230-0203 replacement motor fits to following chillers and cooling systems: Lytron Kodiak chillers: RC011, RC022, RC030, RC045 Lytron Modular Cooling System: MCS50

NTC Thermistor;±1,0°C;10 kΩ @25°C;Cylindrical

Benchtop;5 A

Benchtop;15 A

Output Current Range (I): 0 – 15 A; Output Voltage Range (0.84*Vin max) (V): 1 – 40 V; Output Power Range 0 – 600 W; TEC Temperature Set Step; 0.01 °C; Temperature Control Range: 0 - +80 °C; NTC Feedback Sensor: 1/ 2.2/ 4.7/ 6.8/ 10/ 22/ 47 kΩ; Current Stability: < 0.2 %The TCXXXX series consists of high-power, compact OEM TEC controllers. These controllers feature unique circuit solutions that enable high efficiency (up to 97%) and high power density. An aluminum base plate effectively dissipates heat from the controller using either water or air cooling. TEC controllers are equipped with numerous protection features to ensure the safe operation of Peltier devices. They are primarily used for temperature stabilization in laser diodes, LEDs, semiconductor devices, optics, fibers, chemical elements, and more.Key features: Ultra compact: 57.9 x 36.8 x 21 mmVery high efficiency up to 97%Temperature stabilization range 0°C to 80°CLow current ripple ≤ 35mAIntegrated PID controllerAnalog Control Signal/ RS-232/ UART/ RS-485/ I2C/ USB available as a paid optionAdjustable TEC output current & voltage limitStandalone modeWorking with NTC sensors 1kΩ/ 2.2kΩ/ 4.7kΩ/ 6.8kΩ/ 10kΩ/ 22kΩ/ 47kΩRoHS3 compliantAndroid app (requires UART/Bluetooth as a paid option)LabView driverFree softwareApplications: Temperature stabilization of laser diodes, LED, semiconductor devices, optics, fibers, chemical elements and others
