RWL Single Mode Laser Diodes

Product number: SW10675

Manufacturer: TOPTICA eagleyard

Product information "RWL Single Mode Laser Diodes"

Ridge Waveguide Fabry-Perot Laser Diodes; 808-1060 nm; Spectral Width 0.3-3 nm; Output Power 100-800 mW; Threshold Current ≤70-300 mA; Slope Efficiency 0.8, 0.9 W/A; Forward Current 170 to 1,500 mA

Toptica eagleyard’s RWL series of Fabry-Perot ridge waveguide laser (RWL) diodes operate on a single transverse resonator mode. This leads to high power output (100 up to 800 mW in cw mode) with diffraction limited beam profile. However, multiple axial (longitudinal) modes may occur which can lead to differing optical frequencies. The frequencies are separated by the free spectral range of the resonator given by the reflecting facets of the laser chip.

Additional features such as collimation optics for optimum beam quality or a thermoelectric cooling module for more stable frequency performance can be integrated in the package on request. Direct temperature control of the chip enables optimum wavelength stability and better heat dissipation under continuous high-power operation.

Key Features:

Fabry-Perot Edge-emitting Ridge Waveguide Laser Diodes
Broad Wavelength Range: 808 to 1060 nm
Typ. Spectral Width: 0.3, 1 nm
Output Power: 100 to 800 mW CW
Good Beam Quality (typ. M2 = 1.1)
Cavity Length: 1300 to 4400 µm
Beam Divergence: Parallel (Slow Axis) 5° to 10° (FWHM), Perpendicular (Fast Axis) 14° to 30° (FWHM)
Package Types: Standard Butterfly, Butterfly With Window, SOT 9x2.45 mm, SOT 9x3.65 mm, Flatpack With Window

Product	Wavelength	Output Power	Operational Mode	Package	Specifics
RWL-0808-00400-4000-BFY02-0000 (NEW)	808 nm	400 mW	CW	Hermetically Sealed Butterfly	PM Fiber Output, Monitor Diode, TEC, Thermistor
RWL-0808-00800-4000-BFW09-0000	808 nm	800 mW	CW	Hermetically Sealed Butterfly With Window	Collimated Beam, Monitor Diode, TEC
RWL-0850-00100-1500-SOT12-0000	850 nm	100 mW	CW	SOT 9 x 3.65 mm	Monitor Diode
RWL-1060-00750-4000-FLW01-0006	1060 nm	750 mW	CW	Flatpack With Window	-
RWL-1060-00100-1300-SOT01-0000	1060 nm	100 mW	CW	SOT 9 x 2.45 mm	Monitor Diode

Applications: Laser Source for Precise Positioning; Laser Source for Surface Profiling with DOE; Pump Laser for DPSS and Fiber Laser; Free Space Optical Data Communication
