Fiber-coupled Diode Laser Systems

405-976 nm; Output Power 0.002-12 W; Fiber Core Diameter 4-400 µm; Fiber NA 0.13, 0.14, 0.22BWT provides a broad range of single-emitter diode lasers with wavelengths from 405 nm to 97 6nm and output powers from 2 mW to 12 W. Variants with wavelengths in the area of 9xx nm (915 nm to 976 nm) are especially suited for pumping of fiber lasers and solid state lasers. Further areas of applications are computer to plate (CTP) printing, medical, aiming beam, industry and others.BWT’s high-power diode laser modules are manufactured by adopting specialized fiber coupling techniques. Using special micro optics, the asymmetric radiation from the laser diode chip is transferred into an output fiber with small core diameter. The result are volume products with a high efficiency, stability and superior beam quality.Inspecting and burn-in procedures guarantee each product with reliability, stability and long lifetime. For customer-specific applications, varieties of packages as well as optional functions like aiming beam, photo detector, TEC, fiber detector, thermistor and other functions are available. Contact the AMS Technologies diode laser experts to discuss your customized diode laser solution.   Item Number Wavelength Power Fiber Core Diameter Fiber Numerical Aperture  Features Applications Download K405E03CN-0.160W 405 nm 160 mW 40 µm 0.22   Printing Datasheet K450FFBFN-0.800W 450 nm 800 mW 105 µm 0.22   Biochemical Analysis; Scientific Research; Printing Datasheet K520F03SN-0.005W 520 nm 5 mW 4 µm 0.13   Aiming Beam Datasheet K520F03FN-0.010W 520 nm 10 mW 105 µm 0.22   Aiming Beam Datasheet K635F03RN-0.002W 635 nm 2 mW 4 µm 0.13 1040-1200 nm Feedback Protection Aiming Beam for Fiber Laser; Printing; Medical; Scientific Research Datasheet K635F03RN-0.020W 635 nm 20 mW 4 µm 0.13 1040-1200 nm Feedback Protection Aiming Beam for Fiber Laser; Printing; Medical; Scientific Research Datasheet K785AFLFN-0.600W 785 nm 600 mW 105 µm 0.22 Δλ<0.12 nm Raman Spectroscopy; Sensing; Medical Datasheet K785AFLWN-0.600W 785 nm 600 mW - - Δλ<0.12 nm Raman Spectroscopy; Sensing; Medical Datasheet K793DB2RN-4.000W 793 nm 4 W 105 µm 0.22 1900-2100 nm Feedback Protection Fiber Laser Pumping; Solid State Laser Pumping Datasheet K808F11CA-4.000W 808 nm 4 W 200 µm 0.22   Medical; Material Processing Datasheet K808DB2RN-8.000W 808 nm 8 W 105 µm 0.22   Solid State Laser Pumping; Medical; Material Processing Datasheet K808F14CA-8.000W 808 nm 8 W 400 µm 0.22   Medical Datasheet K830AFLWN-0.600W 830 nm 600 mW - - Δλ<0.12 nm Raman Spectroscopy; Sensing; Medical Datasheet K830AFLFN-0.600W 830 nm 600 mW 105 µm 0.22 Δλ<0.12 nm Raman Spectroscopy; Sensing; Medical Datasheet K830F02FN-1.000W 830 nm 1 W 50 µm 0.14   CTP Printing Datasheet K830F02FN-2.000W 830 nm 2 W 50 µm 0.14   Flexo Printing Datasheet K915FB2RN-10.00W 915 nm 10 W 105 µm 0.22   CATV; Fiber Laser Pumping; Medical; Material Processing Datasheet K915FB2RN-12.00W 915 nm 12 W 105 µm 0.22   Fiber Laser Pumping; Medical; Material Processing Datasheet K940EB2RN-10.00W 940 nm 10 W 105 µm 0.22   Fiber Laser Pumping; CATV Datasheet K976AB2RN-3.000W 976 nm 3 W 105 µm 0.22 Wavelength-stabilized, Δλ<0.7 nm, 1020-1200 nm Feedback Protection Fiber Laser Pumping Datasheet K976AB2RN-9.000W 976 nm 9 W 105 µm 0.22 Wavelength-stabilized, Δλ<0.7 nm, 1020-1200 nm Feedback Protection Fiber Laser Pumping Datasheet K976DB2RN-10.00W 976 nm 10 W 105 µm 0.22 1020-1200 nm Feedback Protection Laser Pumping; Medical; Material Processing Datasheet K976F11CA-10.00W 976 nm 10 W 200 µm 0.22 Customer Options:  Aiming Beam, Power PD, Thermistor, Reflective Fiber Detection Sensor Medical; Material Processing Datasheet K976F14CA-10.00W 976 nm 10 W 200 µm 0.22 Customer Options:  Red Aiming Beam, Power PD, Thermistor, TEC Medical; Material Processing Datasheet  Applications: Pumping of Fiber Lasers and Solid State Lasers; Biochemical Analysis; Scientific Research; Computer to Plate(CTP) Printing; Aiming Beam; Medical; Material Processing; Raman Spectroscopy; Sensing; CATV

440-1064 nm; Output Power 0.4-330 W; Fiber Core Diameter 105-400 µm; Fiber NA 0.22 BWT’s broad range of fiber-coupled multi-single emitter diode lasers are built upon the foundation of multi-emitter coupling technology to obtain high-power and high-brightness diode lasers. BWT’s multi-single emitter diode lasers cover a wavelength range from 440 nm to 1064 nm with output powers from 0.4 W to 330 W. Variants with wavelengths in the area of 9xx nm (915 nm to 976 nm) are especially suited for pumping of fiber lasers and solid state lasers. Further areas of applications are material processing, 3D printing, illumination, aiming beam, a broad range of life sciences and others. Multi-single emitter diode lasers have great advantages in high reliability and high performance. BWT has patented many improved optical designs for this type of lasers. Compact packages and commercially recognized formats allow easy integration into existing products. Inspecting and burn-in procedures guarantee each product with reliability, stability and long lifetime. For customer-specific applications, varieties of packages as well as optional functions like aiming beam, photo detector, TEC, fiber detector, thermistor and other functions are available. Contact the AMS Technologies diode laser experts to discuss your customized diode laser solution. Item Number Wavelength Power Fiber Core Diameter Fiber Numerical Aperture Features Applications Download K440FA5FN-30.00W 440 nm 30 W 105 µm 0.22   Material Processing; 3D Printing Datasheet K440FA5CN-30.00W 440 nm 30 W 200 µm 0.22   Material Processing; Medical; 3D Printing Datasheet K445F03FN-3.000W 445 nm 3 W 105 µm 0.22   Biochemical Analysis; Scientific Research Datasheet K445FTRFN-20.00W 445 nm 20 W 105 µm 0.22   Illumination; Scientific Research; Material Processing; 3D Printing Datasheet K445FTRFN-50.00W 445 nm 50 W 200 µm 0.22   Scientific Research; Material Processing; 3D Printing Datasheet K445FGRFN-200.0W 445 nm 200 W 200 µm 0.22   Material Processing; 3D Printing Datasheet K635F03RN-0.400W 635 nm 400 mW 105 µm 0.22 1040-1200 nm Feedback Protection Aiming Beam for Fiber Laser; Printing; Medical; Scientific Research Datasheet K635F15FN-1.800W 635 nm 1.8 W 105 µm 0.22   Aiming Beam Datasheet K635EWDFN-5.000W 635 nm 1.8 W 105 µm 0.22   Medical; Aiming Beam; Scientific Research Datasheet K793DA2RN-8.000W 793 nm 8 W 105 µm 0.22 1900-2100 nm Feedback Protection Fiber Laser Pumping; Solid State Laser Pumping Datasheet K793DA3RN-12.00W 793 nm 12 W 105 µm 0.22 1900-2100 nm Feedback Protection Fiber Laser Pumping; Solid State Laser Pumping Datasheet K793DAERN-16.00W 793 nm 16 W 105 µm 0.22 1900-2100 nm Feedback Protection Fiber Laser Pumping; Solid State Laser Pumping Datasheet K793DA5RN-30.00W 793 nm 30 W 105 µm 0.22 1900-2100 nm Feedback Protection Fiber Laser Pumping Datasheet K793DG5RN-50.00W 793 nm 50 W 105 µm 0.22 1900-2100 nm Feedback Protection Fiber Laser Pumping Datasheet K793DN2RN-80.00W 793 nm 80 W 200 µm 0.22 1900-2100 nm Feedback Protection Fiber Laser Pumping; Solid State Laser Pumping Datasheet K793DN1RN-90.00W 793 nm 90 W 106.5 µm 0.22   Laser Pumping Datasheet K793DN2RN-140.0W 793 nm 140 W 200 µm 0.22 1900-2100 nm Feedback Protection Fiber Laser Pumping Datasheet K793DN2RN-180.0W 793 nm 180 W 200 µm 0.22 1900-2100 nm Feedback Protection Fiber Laser Pumping; Solid State Laser Pumping Datasheet K808F02MN-10.00W 808 nm 10 W 400 µm 0.22   Illumination; Medical; Laser Pumping; Material Processing Datasheet K808F04MN-15.00W 808 nm 15 W 400 µm 0.22   Illumination; Medical; Laser Pumping; Material Processing Datasheet K808F04MN-20.00W 808 nm 20 W 400 µm 0.22   Illumination; Medical; Laser Pumping; Material Processing Datasheet K808DAHRN-25.00W 808 nm 25 W 400 µm 0.22   Solid State Laser Pumping; Medical; Material Processing Datasheet K808DAECN-30.00W  808 nm 30 W 400 µm 0.22   Solid State Laser Pumping; Medical; Material Processing Datasheet K808DN1RN-40.00W 808 nm 40 W 106.5 µm 0.22   Fiber Laser Pumping Datasheet K808DA5RN-55.00W 808 nm 55 W 400 µm 0.22   Solid State Laser Pumping; Medical; Material Processing Datasheet K808DN1RN-60.00W 808 nm 60 W 106.5 µm 0.22   DPSS Pumping; Medical; Material Processing Datasheet K808DN2RN-150.0W 808 nm 150 W 400 µm 0.22   Solid State Laser Pumping; Medical; Material Processing Datasheet K878BNXRN-30.00W 878.6 nm 30 W 200/400 µm 0.22   Solid State Laser Pumping Datasheet K878BN0RN-65.00W 878.6 nm 65 W 200 µm 0.22   Solid State Laser Pumping Datasheet K878BN2RN-120.0W 878.6 nm 120 W 200 µm 0.22   Solid State Laser Pumping Datasheet K888BN0RN-65.00W 888 nm 65 W 200 µm 0.22 1020-1200 nm Feedback Protection Fiber Laser Pumping Datasheet K888BN2RN-120.0W 888 nm 120 W 200 µm 0.22 1020-1200 nm Feedback Protection Fiber Laser Pumping Datasheet K915FA3RN-30.00W 915 nm 30 W 105 µm 0.22 1040-1200 nm Feedback Protection Laser Pumping; Medical; Material Processing Datasheet K915FA3RN-35.00W 915 nm 35 W 105 µm 0.22 1020-1200 nm Feedback Protection Laser Pumping; Medical; Material Processing Datasheet K915FNXRN-70.00W 915 nm 70 W 106.5 µm 0.22 1040-1200 nm Feedback Protection Laser Pumping; Medical; Material Processing Datasheet K915FA5RN-70.00W 915 nm 70 W 106.5 µm 0.22 1040-1200 nm Feedback Protection Laser Pumping; Medical; Material Processing Datasheet K915FN1RN-160.0W 915 nm 160 W 106.5 µm 0.22 1020-1200 nm Feedback Protection Fiber Laser Pumping Datasheet K915FN1RN-180.0W 915 nm 180 W 106.5 µm 0.22 1020-1200 nm Feedback Protection Fiber Laser Pumping Datasheet K915-A0-250.0W-13522-D 915 nm 250 W 135 µm 0.22 1020-1200 nm Feedback Protection Fiber Laser Pumping Datasheet K915-A0-300.0W-20022-S 915 nm 300 W 200 µm 0.22 1020-1200 nm Feedback Protection Fiber Laser Pumping Datasheet K940FA2RN-20.00W 940 nm 20 W 105 µm 0.22 1040-1200 nm Feedback Protection Laser Pumping; Medical; Material Processing Datasheet K940FA3RN-30.00W 940 nm 30 W 105 µm 0.22 1040-1200 nm Feedback Protection Laser Pumping; Medical; Material Processing Datasheet K940FA5RN-70.00W 940 nm 70 W 106.5 µm 0.22 1040-1200 nm Feedback Protection Laser Pumping; Medical; Material Processing Datasheet K940FN1RN-150.0W 940 nm 150 W 106.5 µm 0.22 1040-1200 nm Feedback Protection Fiber Laser Pumping Datasheet K940FN1RN-200.0W 940 nm 200 W 135 µm 0.22 1040-1200 nm Feedback Protection Fiber Laser Pumping Datasheet K940FN1RN-200.0W 940 nm 200 W 200 µm 0.22 1040-1200 nm Feedback Protection Fiber Laser Pumping Datasheet K976FANCA-15.00W 976 nm 15 W 200 µm 0.22 Customer Options: Red Aiming Beam, Power PD, Thermistor Medical; Material Processing Datasheet K976AA2RN-18.00W 976 nm 18 W 105 µm 0.22 Wavelength-stabilized, Δλ<0.7 nm, 1020-1200 nm Feedback Protection Fiber Laser Pumping Datasheet K976DA2RN-20.00W 976 nm 20 W 105 µm 0.22 1040-1200 nm Feedback Protection Laser Pumping; Medical; Material Processing Datasheet K976AAHRN-27.00W 976 nm 27 W 105 µm 0.22 Wavelength-stabilized, Δλ<0.7 nm, 1040-1200 nm Feedback Protection Fiber Laser Pumping Datasheet K976DA3RN-30.00W 976 nm 30 W 105 µm 0.22 1040-1200 nm Feedback Protection Laser Pumping; Medical; Material Processing Datasheet K976FANCA-30.00W 976 nm 30 W 200 µm 0.22 Customer Options: Red Aiming Beam, Power PD, Thermistor, Fiber Detector Medical; Material Processing Datasheet K976AA5RN-60.00W 976 nm 60 W 106.5 µm 0.22 Wavelength-stabilized, Δλ<0.7 nm, 1040-1200 nm Feedback Protection Fiber Laser Pumping Datasheet K976DA5RN-70.00W 976 nm 70 W 106.5 µm 0.22 1040-1200 nm Feedback Protection Laser Pumping; Medical; Material Processing Datasheet K976AN1RN-130.0W 976 nm 130 W 105 µm 0.15 Wavelength-stabilized, 1020-1200 nm Feedback Protection Fiber Laser Pumping Datasheet K976BN1RN-140.0W 976 nm 140 W 106.5 µm 0.22 Wavelength-stabilized, 1040-1200 nm Feedback Protection Fiber Laser Pumping Datasheet K976DN1RN-150.0W 976 nm 140 W 106.5 µm 0.22 1040-1200 nm Feedback Protection Fiber Laser Pumping Datasheet K976BN1RN-180.0W 976 nm 180 W 200 µm 0.22 Wavelength-stabilized, 1040-1200 nm Feedback Protection Fiber Laser Pumping Datasheet K976-A0-250.0W-13522-D 976 nm 250 W 135 µm 0.22 1020-1200 nm Feedback Protection Fiber Laser Pumping Datasheet K976-A0-330.0W-20022-S 976 nm 330 W 200 µm 0.22 1020-1200 nm Feedback Protection Fiber Laser Pumping Datasheet KA64HAMCA-10.00W 1064 nm 10 W 200 µm 0.22   Dental; Dermatology; Therapeutic Datasheet KA64HAMCA-15.00W 1064 nm 15 W 200 µm 0.22   Dental; Dermatology; Therapeutic Datasheet KA64HAMCA-20.00W 1064 nm 20 W 200 µm 0.22   Dental; Dermatology; Therapeutic Datasheet   Applications: Pumping of Fiber Lasers and Solid State Lasers; Material Processing, Medical; 3D Printing; Biochemical Analysis; Scientific Research; Illumination; Aiming Beam; Dental; Dermatology; Therapeutic
