WFC Series Film Capacitors

Product number: SW10242

Downloads

WFC Series Film Capacitors NWL-Cornell Dubilier CDE Datasheet

Product information "WFC Series Film Capacitors"

Cornell Dubilier CDE (formerly NWL) pioneered the development of water cooled capacitors and has become the supplier of choice for many induction heating furnace manufacturers worldwide. With decades of design expertise and manufacturing excellence, Cornell Dubilier CDE is one the top manufacturers of water cooled capacitors in the world.

Cornell Dubilier CDE’s WFC-Series water cooled/liquid cooled capacitors provide solutions in a wide variety of induction heating applications, from forging to melting, heat treating and annealing, to billet heating and hardening.

Over 50 electrical configurations are currently available in a welded aluminum package, with the following features and options available upon request:

Pressure switches
Internal discharge resistors
Live or dead case construction
Single to multiple fine-tuning values per capacitor
Choice of bracket style and location
Choice of cooling water connections
Choice of terminal connections

Manufacturer "NWL-Cornell Dubilier CDE"
