UC160 (formerly OASIS) 10-160-G3-P0 TEC Chiller

Compressor-based and Peltier-based Cabinet Coolers; Cooling Capacity 400, 460 W; Power Supply 24 VDC, 13, 43 A; Orientation Flush Mount, Any; External Temperature Range +10-+50°C, -40-+70°C; Protection Level Ambient Side IP65 AMS Technologies provides miniature air cooling kits that allow customers to evaluate cabinet cooling solutions with up to 460 W cooling capacity, as well as a miniature, compressor-based air cooler with 400 W cooling capacity. Our mAC-C-400-24 mini Air Cooler is a compact, compressor-based cabinet cooler for cooling capacities up to 400 W that takes over where Peltier isn’t powerful enough. Its integrated controller drives the speed of the miniature rotary compressor to maintain the set temperature to within ±0.05 K. A powerful fan moves the cabinet internal air at 130 m³/h. The external fan is PWM speed controlled for noise reduction. Miniature rotary compressors as well as customized condensers and evaporators significantly reduce size and weight compared to Peltier-based cabinet coolers, while providing a highly efficient vapor compression circuit. The mAC-C-400-24 can be operated on the cabinet’s 24 VDC voltage rail, independent of mains voltage or frequency. And the mAC-C-400-24 is “IoT ready” – an integrated Ethernet interface allows remote access to system parameters as well as remote control of the cooling system via web browser. Our mAC-T-460-24-KIT mini Air Cooling Kit, a powerful thermoelectric cabinet cooler development kit, is the optimal solution for harsh environments where compressor-based coolers cannot withstand high temperatures, shock and vibration or operation on moving or turning equipment. The Peltier modules can be operated up to 36 VDC when necessary. At nominal 24 VDC and +35°C/+35°C (ambient/internal), the unit reaches a cooling capacity of 460 W and a coefficient of performance (COP) of 0,55. Your customized mAC-KIT: For customer requirements that cannot be covered by the mAC-C-400-24 or the mAC-T-460-24-KIT, our thermal management specialists at AMS Technologies are happy to develop a completely tailor-made solution and offer all services from development and proof-of concept all the way to series production. Get in touch with us now to discuss your customized mAC-KIT. Key Features: Up to 460 W Cooling Capacity (Tchilled cabinet air +35°C, Tambient +35°C, 55% r. h.) Compressor-based: Very Compact & Lightweight Format, ±0.5 K Temperature Stability Peltier-based: No Moving Parts Except for Fans, Independent From Orientation Wide Ambient Temperature Range: +10°C to +50°C (Compressor-based); -40°C to +70°C (Peltier-based) Orientation: Flush Mount, Side Wall or Door (Compressor-based), Any (Peltier-based) Ambient Side Environmental Protection: IP65, Suitable for Harsh Environments Operating Voltage: 24 VDC – Independent of Mains AC Voltage or Frequency Max. Operating Current: 13 A (Compressor-based), 43 A (Peltier-based) IoT Enabled (Compressor-based) Dimensions: 310 × 157 × 475 mm (Compressor-based), 345 × 339 × 155 mm (Peltier-based, +132 mm drop in cabinet) Weight: 15 kg(Compressor-based), 21 kg (Peltier-based) Applications: Cabinet Cooling; Cooling of Air inside Cabinets for Applications With up to 460 W Power Dissipation; Harsh Environments

300x88.9x12.7 mm; Aluminum; Copper Tubes; 4 -PassLCP ET 88,9x12,7x300/4Pass_Cu is an aluminum cold plate combined with 4-pass copper tubes. The exclusive section shape, pressed in the base plates without glues or resins, maximizes adhesion and minimizes any thermal impedance between the tube coil and the plate, both on the straight and curved parts of the design.We can design embedded tube cold plates to be fully customized for the individual needs of each specific design, regardless of the application for which the plate is designed. Get in touch with our thermal experts to discuss your specific requirements.

Vapor Compression Chiller; 450W @+25°C; 230VAC; 2lpm; USB/ Ethernet; Benchtop Key Features: Miniature Recirculating Water Chiller Compact Size, Easy to be Integrated in Customer Application User-Definable PID Parameters and Fan Velocity Calm Operation With Low Vibration and Noise Ideal for Water Cooling Tasks up to 450 W IoT Ready: Remote Operation, Monitoring and Service over Integrated Ethernet Interface Full chiller power in a shoebox form factor: the mRC-C-450-100/240 mini recirculating chiller provides to 450 W cooling capacity and contains a compressor-based refrigerant circuit as well as a closed, recirculating coolant (water) circuit that is pressurized – all that in a compact, 350 x 290 x 230 mm housing. This small size is enabled by utilizing a miniature rotary compressor, customized miniature evaporator and condenser. On the coolant side, pressurizing the circuit allows a very small tank, and a compact centrifugal pump also contributes to reduced space requirements. Due to the speed-controlled compressor, the mRC-C-450-100/240 chiller offers low vibration and noise throughout the compressor’s BLDC speed range. Further features are automatic fill and drain of the coolant circuit, global operability due to a universal 90 to 264 VAC power supply, and an integrated Ethernet interface allowing remote operation, monitoring and service. Specifications: Cooling Capacity: 300 W (Twater = +20°C, Tambient = +40°C) to 500 W (Twater = +20°C, Tambient = +20°C) Temperature Stability: +2/-1.5 K Over-/undershoot at 250 W Heat Load ON/OFF, Down to 0.05 K Continuous Operation Available Pressure Head: 1.5 bar @1 lpm; 0.5 bar @5.5.lpm Noise Level: 63 dBA (fan 40%, compressor 100%) Control: Local, USB/Serial, Internet (Web Browser) via Ethernet (IoT Ready) Interlock I/O Alarms: Liquid Level, Tank Pressure, Coolant Feed Temperature, Coolant Flow Rate, Condenser Pressure Power Supply: 90 to 264 VAC, 24 VDC Derivative Available on Demand Power Consumption: <300 W Dimensions: 350 x 280 x 230 mm, Main Body Without Filter Weight: 13 kg Approval: CE Applications: Water Cooling of Lasers and Other Applications; Integration of Water Cooling Capabilities in Systems with Limited Space

230W @ 20°C; >2 lpm @ 14 psig; 1/4" valved CPC Fittings; Centrifugal Pump; Aluminium and Polymers This thermoelectric recirculating chiller is a low-cost, high-performance device optimized for lasers, optics and life sciences. It features precise temperature control (±0.05°C repeatability), long-life reliability, quiet operation and environmental friendliness in a compact size. Using universal power, the TEC chiller is very energy efficient only drawing power when required.

Cabinet Cooler - 100W Cooling Capacity - TEC based – PK 100-24

980 to 1625 nm; Reflectance Range 2 to 60 dB; Fiber Type SM, MM, PM; PDL 0.05, 0.08 dB; Optical Max. Power Level Continuous 500 mW (MM), 50 mW (SM) OZ Optics’ DR-100 series of digital variable reflectors enables the user to generate a known level of return loss to evaluate system response. The unit allows testing the return loss sensitivity of devices such as laser diodes, transmitters, isolators and so on. By generating a precise reflection level, system performance (bit error rate, noise levels, isolator performance) can be evaluated. A built-in calibration table accurately defines intermediate degrees of reflection from 2 dB to as high as 60 dB for different wavelengths. DR-100 digital variable reflectors are offered using either single mode (SM), multi mode (MM), or polarization maintaining (PM) fibers. In general, OZ Optics uses polarization maintaining fibers based on the PANDA fiber structure when building polarization maintaining components and patch cords. However OZ Optics can construct devices using other PM fiber structures. OZ Optics also carries some alternative fiber types in stock, please contact AMS Technologies for availability. If necessary, OZ Optics is willing to use customer supplied fibers to build devices. For best results, the standard versions of the DR-100 series are designed to accept angled FC/PC connectors. Other connector types are possible with lower dynamic reflectance range. DR-100 digital variable reflectors can be controlled remotely via a USB interface. A universal AC/DC power supply is included with all units. The DR-100 digital variable reflectors can also be provided with a custom built-in fused coupler which directs a fraction of the reflected light to a second optical connector on the unit. The user can use this signal for monitoring the reflected power or determining the influence of reflected power on his device under test. For details, please contact AMS Technologies. Key Features: High Speed Wide Reflectance Range: 2 to 60 dB Low Insertion Loss High Resolution Rugged and Compact Design Wide Wavelength Range: 980 to 1625 nm Can Be Calibrated for Dual Wavelengths Wide Range of Connectors Polarization Insensitive USB Communications Interface Applications: Bit Error Rate Testing; Troubleshooting Receivers and Other Active Fiber Optic Components; Design of Fiber Optic Transmitter/Receiver Circuitry
