R Series Film Capacitors

Product number: SW10244

Product information "R Series Film Capacitors"

Cornell Dubilier CDE (formerly NWL)’s R-Series is a unique family of capacitor product that exhibits superior performance with high current and high frequency applications. By utilizing low inductance internal constructions, optional molded resin cases, and customized terminations, R-Series capacitors are designed for fast switching IGBTSs and can serve as snubbers and high current high frequency input filters.

R-Series capacitors are well suited for many inverter applications including:

Snubber capacitors
High current DC input filters
High frequency DC input filters
Low inductance fast reactive clamp capacitors

Unique features of the R-Series capacitor include:

IGBT direct mount option – With high current robust terminals spaced to match IGBT centers, Cornell Dubilier CDE’s R-Series capacitors can directly mount onto input connections on IGBTs.
Low inductance packages – With the R-Series capacitors’ dry resin filled construction, some unique internal laminated low impedance bus bar and terminal construction produce extremely low inductance values.
High heat dissipation package – The R-Series capacitors can also utilize a resin mold package, combined with copper terminals to providing the best thermal heat dissipation systems available.

Manufacturer "NWL-Cornell Dubilier CDE"
