P800 Recirculating Chillers

0

Liquid to Ambient Air Cooling System; 1,300 to 3,500 W @ 25 K initial temperature difference; Modular; 230, 115 V; 4.9 to 8.7 l/min @2.1 bar Lytron’s MCS series of modular liquid cooling systems are a cost-effective and reliable option where precise temperature control and cooling below ambient temperature are not required. These systems consist of a high-performance heat exchanger integrated with a fan, pump and tank in a durable metal chassis. MCS modular liquid cooling systems feature cooling capacities of up to 3.5 kW. Components of MCS modular liquid cooling systems are performance-matched for maximum cooling capacity. The most critical component, the heat exchanger, is designed for optimum performance. All components have been designed for long life and high reliability. Lytron offers systems that are compatible with a range of coolants, ensuring there is an option available for nearly every fluid. MCS modular liquid cooling systems are easy to use with installation instructions as simple as completing the liquid loop, filling the liquid reservoir tank and flipping the switch. These systems offer a fast option for upgrading to liquid cooling in a cost effective and reliable package. Key Features: Cooling Capacity: 1,300 to 3,500 W @ 25 K initial temperature difference (hot coolant temperature  – cold ambient air temperature)  Fluid Connections: ½” FNPT Reservoir Capacity: 2.8 l Maximum Liquid Temperature: +55 °C Recommended Coolant: Water (MCS30: Oil, EGW) Pump Performance: 4.9 to 8.7 l/min @ 2.1 bar Dimensions: 439 x 384 x 338 mm (MCS20/MCS30), 381 x 381 x 610 mm (MCS40/MCS50) Applications: Power Supply Cooling; Power Conversion Cooling; Process Automation Systems; Security Screening; Sample Test Equipment Cooling Systems; Diagnostic Systems; Medical Lasers; MRI; Edge Computing Center Cooling Systems

Cooling Capacity 200 to 500 W @+20 °C; Process Fluid Flow Rate 1.5 to 3.0 lpm @ 30 psig; 1/4” John Guest or Other Fittings; 9 Diaphragm, Gear or Centrifugal Pump Options; Wetted Materials Al, Cu or Stainless Steel Cold PlateThe ThermoCube II 200–500 Thermoelectric Chillers from Solid State Cooling Systems are engineered for precision temperature control in laboratory, analytical, and OEM environments. These advanced benchtop chillers offer configurable cooling capacities ranging from 200 to 500 watts, delivering exceptional thermal stability and repeatability. Built on robust thermoelectric technology, the ThermoCube II eliminates the need for compressors and refrigerants, offering a quiet, low-maintenance solution for applications where uptime and accuracy are essential.Compact yet powerful, the ThermoCube II measures 11 x 13 x 13 inches (28 x 32 x 33 cm) and weighs just 28 lbs (12.7 kg), making it ideal for installations with limited space. The standard operating range of 5°C to 50°C can be extended to -5°C or up to 65°C with optional configurations. A digital PID controller ensures ±0.05°C temperature stability, while the modular design allows users to tailor the unit to specific process requirements.Key FeaturesHighly Configurable Design: Four base models with options for extended temperature ranges, flow meters, leak detectors, and alternate fluids.Thermoelectric Cooling: Solid-state technology ensures quiet operation, low vibration, and long service life without refrigerants.Advanced Control & Communication: RS232, RS485, Ethernet, TTL, and keypad interface for seamless integration into automated systems.Flexible Pump & Fitting Options: Six pump types (diaphragm, centrifugal, gear) and nine fitting choices (John Guest, CPC, APC, Swagelok, NPT).Compact Footprint: Fits easily on lab benches or within OEM enclosures; universal power input (100–240 VAC, 50/60 Hz).Quiet Operation: Below 50 dBA at 50% load and under 63 dBA at full load.Safety & Compliance: Alarms for temperature, fluid level, and system faults; UL, CE, CAN/CSA, and RoHS certified.ApplicationsAnalytical Instruments: Spectroscopy, chromatography, and mass spectrometry systems requiring stable thermal environments.Laser & Photonics Systems: Diode lasers and optical components needing precise temperature regulation.Life Sciences & Biotech: Microfluidics, sample preparation, and temperature-sensitive assays.OEM Integration: Medical, diagnostic, and scientific equipment with space and control constraints.Imaging Systems: CCD and CMOS sensors used in low-light or high-resolution imaging applications.What's Next?If your application demands precise, reliable, and customizable thermal control, the ThermoCube II 200–500 Thermoelectric Chillers offer a proven solution. With over 34,000 units shipped globally, this platform is trusted by researchers and engineers for its performance and adaptability.Contact our sales team today to discuss your requirements, request a quote, or explore configuration options tailored to your system.
