OLS7 Series Optical Liquid Level Sensors

Cynergy 3 Components-Sensata Technologies

Product number: SW11842

Downloads

OLS7 Series Optical Liquid Level Sensors Cynergy3 - Sensata Datasheet

Product information "OLS7 Series Optical Liquid Level Sensors"

The OLS7 series is a liquid level sensor for single point liquid level detection. The sensor has an infra-red emitter and detector aligned within an accurately shaped cone to give good optical coupling when the sensor is in air. This coupling is greatly reduced, when the sensor is immersed in liquid, as the infra-red light escapes through the liquid rather than being reflected back to the detector.

The sensor has a transistor output, so it can be configured by the user for particular applications.

Key Features:

Optical Liquid Level Sensor 1/4”NPT Mount
Low-cost Sensors for General Liquid Sensing
High-reliability Optical Sensing
External Mount via 1/4”NPT Thread
Standard Temperature Range: -25ºC to +80ºC
Extended Temperature Range: -40ºC to +125ºC
High and Low Output Versions
Resistant to False Triggering Caused by Foaming
Body Material: Polysulfone UDEL 1700
Maximum Pressure: 7 bar
Tightening Torque for Fixing: 1.5Nm
Cable Length - Standard: 25 cm
Wire Size: 24AWG
Cable Conductor Material: Tinned Copper
Wire Sheath Material :PTFE
Wire Temperature Rating: +125ºC
Sealing Gasket Not Supplied
Supply Voltage (Vs): 4.5 to 15.4 VDC or 10 to 28 VDC
Supply Current Max (Is): 2.5 mA (Vs = 15.4 VDC)
Output Type Voltage: High or Low
Output Voltage (Vout) @ lout =100 mA: Output High Vout = Vs-1 Vmax, Output Low Vout = 0.5 Vmax
Output Sink & Source Current lout: 100 mA Max. or 1 A

Manufacturer "Cynergy 3 Components-Sensata Technologies"
