MBL 1500A Laser Diode Drivers and TEC Temperature Controllers

Product number: SW10877

Downloads

Laser Diode Drivers & Temperature Controllers AMS Technologies Brochure
MBL 1500A Laser Diode Driver and TEC Temperature Controllers Maiman Electronics Datasheet

Product information "MBL 1500A Laser Diode Drivers and TEC Temperature Controllers"

Output Current LD 1.5 A; Output Current TEC ±4 A; Benchtop or Rack Mount; Compatible with Butterfly Type 1 & Type 2 Lasers; Current Stability <0.1%

Maiman Electronics’ MBL1500A laser diode driver and TEC Temperature Controllers is designed for driving laser diodes in both Type 1 (Pump) and Type 2 (Telecom) 14-pin butterfly packages. The MBL1500A benchtop format drivers include a high stability (0.01 mА) current source for the laser diode and a thermoelectric Peltier cooler (TEC). The laser diode mount is also included on-board with an Azimuth ZIF socket, compatible with Type 1 and Type 2 pinouts of 14-pin butterfly laser diodes.

The laser diode driver channel provides current of up to 1.5 A with not more than 10 to 15 µA of noise. The TEC driver channel provides a temperature change from +12 to +40 °C with a stability of 0,01 °C. In addition, the TEC channel contains an integrated self-adjusted PID controller, keeping the temperature of the Peltier element with high precision within ±0,01 °C.

The MBL1500A driver can be controlled from the front panel using buttons and/or touchscreen or remotely via USB. With these features, MBL1500A is an excellent choice for laboratory test set-ups and has all the necessary protections for safe operation of laser diodes.

Key Features:

All-in-One Current Source, Temperature Controller and Mount with Azimuth ZIF Socket for Butterfly LD
Compatible With Type 1 and Type 2 Butterfly 14-pin Laser Diodes
Controlled Locally With Touch Screen or Buttons
Controlled Remote Over USB (Software and Communication Protocol Included)
Integrated PID Controller, Does Not Require Setup
Soft-Start Current Ramp, Current Protection, Temperature Protection for Laser Diode
Option to Save 9 Presets
Current Stability <0.1%
Free Software
Dimensions: 271 x 257 x 117 mm

Applications: Supplying Laser Diodes in Butterfly Package; Laser Pumping; Laser Spectroscopy; Laboratory Test Set-ups
