LD5020VB Precision Molded Aspheric Lens
€43.94*
Content:
1 pcs
Available in 30 days, delivery time 1-2 days
Product number:
C027229-1
Manufacturer:
GH Optics
Product information "LD5020VB Precision Molded Aspheric Lens"
EFL 5.00 mm; NA 0.15; CA 1.60 mm; OD 2.00 mm; D-ZK3 Glass
The Zemax file of this lens can be downloaded here: file.
The Zemax file of this lens can be downloaded here: file.
Do you need...
- a different coating? A range of standard coatings is available, click here to select your coating option.
- a mounted aspheric lens? Click here to learn more
- a customised lens? Click here to contact us!
Manufacturer "GH Optics"
Founded by a team of optical experts with more than ten years of experience in the optical industry, GH Optics focuses on the design, development and series production of precision optics. Among the core competences of the manufacturer are the processing of optical glass preforms (VIS and IR) including polishing, grinding and CNC machining, as well as precision molding of aspheric lenses.
Using advanced technologies, GH Optics can coat components with a wide portfolio of materials for wavelengths ranging from 350 nm to 14 µm. The supplier also offers optical assembly, ranging from mounted lenses and thermal imaging assemblies to modules and complex optical systems. A full set of qualification and test capabilities guarantees high and consistent product quality of the products. All products supplied by GH Optics are RoHS compliant.
GH Optics’ standard catalog products range from precision molded aspheric lenses for the visible (VIS) and infrared (IR) range, mounted aspheric lenses and fiber collimators to thermal imaging lens assemblies and freeform optics. Beyond its catalogue products, GH Optics specifies, develops and manufactures customized optical solutions according to the customer’s specifications and requirements.
Related links of the manufacturer
Information on the manufacturer (information obligations under the GPSR Product Safety Regulation)
GH Optics (Jiangsu) Co., Ltd
No. 298 Daijiamen Road
Jiangsu Sheng, China
