CHL Series Metallized Film Capacitors
Product information "CHL Series Metallized Film Capacitors"
0.1 µF to 2.5 µF ; 400 kV to 700 kv; SMAX 160 kVA
- Up to 700 VRMS Working Voltage
- 160 kVA Max Power
- Up to 400 ARMS Max Current
- Conduction Cooled
- Series & Parallel Stackable
This series of metallized film capacitors basically consists of a wound core soldered between copper terminals. This wound core is composed of two metallic electrodes separated by an insulating dielectric, a thin film of polypropylene. Among the many possible types of core windings in our wide range of metallized film capacitors, the engineers select the type that optimizes the component for a particular mission profile.
Due to the materials selected and the special design, these high power capacitors are very robust and reliable (self-healing). The metallized film capacitors offer high capacitance in a small package and allow for parallel or serial stacking. They are conduction cooled, can pass high reactive currents without failure withstand very significant voltage potentials without damage.
Specifications
- Capacitance Range 0.1 to 2.5 µF standard; 0.01 to 0.33 custom
- Capacitance Tolerance ± 10 % standard, other tolerances available
- Dimensions 68 x 32 x 30.2 mm, 2 11/16 x 1 1/4 x 1 3/16 inch
- Weight 0.5 kg; 1.1 lb
- Operating Temperature Up to +90 °C
- Cooling method Conduction-cooled by bus bars
- Dissipation Factor 0.1 % Maximum
- Stray Inductance less than 5 nH
