6220G1SB - 6000 Series - Copper tube- fin, heat exchanger

The AMS-195-1.0-0.8 is a high-performance thermoelectric cooler (TEC) designed for precise thermal control in industrial, medical, and scientific applications. With a Qmax of 86W and a maximum temperature differential (dTmax) of 68K, this rectangular Peltier module (25x50 mm) provides efficient and stable cooling for semiconductors, laser systems, medical devices, and industrial electronics.Built with high-quality Al₂O₃ ceramic materials, this TEC module ensures exceptional heat dissipation, structural durability, and long-term operational reliability. Its low electrical resistance (Rac 3.2Ω) enhances power efficiency, making it an ideal choice for high-performance cooling applications.Key FeaturesSuperior Cooling Capacity – Provides a Qmax of 86W, ensuring efficient heat dissipation for demanding applications.Optimized Electrical Efficiency – Operates at Umax 24.1V and Imax 5.8A, delivering stable and energy-efficient cooling.Wide Temperature Differential – With a dTmax of 68K, this TEC module offers precise thermal control in diverse environments.Rectangular and Compact Design – Features a 50x25 mm form factor with a 3.1 mm height, making it suitable for compact cooling systems.High-Quality Ceramic Construction – Built with Al₂O₃ ceramic, providing superior thermal conductivity and mechanical stability.Low Electrical Resistance for Maximum Efficiency – With Rac of 3.2Ω, it minimizes power loss while maintaining optimal cooling performance.Reliable Lead Wires – Equipped with 22 AWG wires, featuring 200mm stripped leads without tinning, ensuring secure electrical connections.ROHS Compliant and Epoxy-Sealed – Designed for long-term durability and environmental safety, ensuring compliance with industry standards.ApplicationsSemiconductor Thermal Management – Provides efficient cooling for high-performance chips, processors, and sensors, preventing overheating and improving system efficiency.Medical and Laboratory Equipment – Ensures precise temperature stability in diagnostic instruments, cryogenic research devices, and laser-based medical systems.Laser and Optoelectronic Systems – Supports efficient heat dissipation in high-power laser diodes, optical sensors, and photonic instruments.Industrial Electronics and Instrumentation – Maintains stable operating temperatures for precision testing equipment, automated systems, and electronic control units.Aerospace and Automotive Thermal Management – Provides reliable cooling solutions for high-performance automotive, aerospace, and satellite applications.What’s Next?The AMS-195-1.0-0.8 Thermoelectric Cooler is an energy-efficient, compact TEC module, ideal for critical applications requiring precise thermal regulation. With its advanced thermoelectric technology, this module ensures long-term durability and optimal cooling efficiency for high-performance cooling solutions.For technical support, product availability, or customized thermal solutions, consult a thermal engineering expert to integrate this TEC into your system.

Copper Fins; Stainless Steel Tubes; 148.3x139.6x46.5 mm; 6-pass; 60 barWater-to-air heat exchangermain dimensions HX housing: 148,3 mm x 139,6 mm x 46,5 mmTubes and tube connections: stainless steel 316L, OD 3/8"Connection tube length 53 mm6 pass, return-bends weldedCorrugated copper fins; thickness 0,12 mm; 18 fpiHX housing and end plates: stainless steel 304/316LHX housing including fan mount, with M4 cage-nuts/press-nutsSpecified fluid pressure: max. 60 bar
