XXHV Series HV Reed Relays
Product number:
SW11862
Product information "XXHV Series HV Reed Relays"
High Voltage Reed Relays
Key Features:
-
6 VDC, 12 VDC & 24 VDC Operating Coil Voltages
-
Form A (N/O) and Form B (N/C) Versions
-
Max. Switching Voltage: 1750 VDC to 5000 VDC
- Max. Switching Current: 3 A (DC/RMS)
- Max. Carry Current: 4.5 A (DC/RMS)
- Max. Switching Power: 50 W (Resistive)
- Min. Isolation Voltage: 3500 to 10000 VDC
Manufacturer "Cynergy 3 Components-Sensata Technologies"
Related links of the manufacturer
Similar products
4 Series RF Reed Relays
€9,999.00*
Miniature Screened 3.5 A; 3.5 kV
The 4 series is a highly flexible, low cost package for RF applications in the 1-30MHz band. The use of vacuum reed switches with Rhodium contacts offers high isolation voltages, low contact resistance and long operating lifetime. Additional RF screening is available to further enhance RF performance for more demanding applications. Available as Form A (SPNO), Form B (SPNC) or latching (bistable) contact configurations with switch connections via either PCB or flying lead.
Product number:
SW10197
Manufacturer:
6 Series RF Reed Relays
€9,999.00*
Miniature Fully Screened 4 A; 3.5 kV
The 6 series is a fully screened relay offering low RF loss and high current carrying capacity, which was developed with RF design engineers in the radio communications industry.
Product number:
SW10198
Manufacturer:
D Series Flying Lead Connection HV Reed Relays
10 & 15 kV isolation; 50 W; Flying Lead Connection
The very high isolation voltages of the D series, up to 15kV, are achieved through the use of high vacuum reed switches with either Rhodium or Tungsten contacts and make these relays suitable for high reliability applications such as cardiac defibrillators, test equipment and high voltage power supplies. The Rhodium contacts have low contact resistance while the Tungsten contacts can switch higher voltages.
Product number:
SW10204
Manufacturer:
D Series Panel Mount HV Reed Relays
10 & 15 kV isolation; 50 W; Panel Mount
The very high isolation voltages of the D series, up to 15kV, are achieved through the use of high vacuum reed switches with either Rhodium or Tungsten contacts and make these relays suitable for high reliability applications such as cardiac defibrillators, test equipment and high voltage power supplies.
Product number:
SW10207
Manufacturer:
D Series PCB Connection HV Reed Relays
10 & 15 kV isolation; 50 W; PCB Connection
The very high isolation voltages of the D series, up to 15kV, are achieved through the use of high vacuum reed switches with either Rhodium or Tungsten contacts and make these relays suitable for high reliability applications such as cardiac defibrillators, test equipment and high voltage power supplies.
Product number:
SW10205
Manufacturer:
D Series Spade Connection HV Reed Relays
10 kV isolation; 50 W; Spade Connection
The very high isolation voltages of the D series, up to 10kV, are achieved through the use of high vacuum reed switches with either Rhodium or Tungsten contacts and make these relays suitable for high reliability applications such as cardiac defibrillators, test equipment and high voltage power supplies.
Product number:
SW10208
Manufacturer:
D Series Turret Connection HV Reed Relays
10 & 15 kV isolation; 50 W; Turret Connection
The very high isolation voltages of the D series, up to 15kV, are achieved through the use of high vacuum reed switches with either Rhodium or Tungsten contacts and make these relays suitable for high reliability applications such as cardiac defibrillators, test equipment and high voltage power supplies.
Product number:
SW10206
Manufacturer:
D-HR Series HV Reed Relays
High Insulation Resistance, High Voltage Relays - 5 kV; 7.5 kV; 10 kV & 15 kV
Very high isolation voltages - up to 15kV - are achieved through the use of high vacuum reed switches with either Rhodium or Tungsten contacts and make these relays suitable for high reliability applications such as cardiac defibrillators, test equipment and high voltage power supplies. The Rhodium contacts have low contact resistance while the Tungsten contacts can switch higher voltages.
Product number:
SW10210
Manufacturer:
D1 Series D Size Form C HV Reed Relays
The D1 series is a reed relay with changeover contacts which are often used in safety critical applications. The switching is achieved through the use of high vacuum reed switches with tungsten contacts.
These relays are suitable for high reliability applications, such as test equipment and high voltage power supplies. These devices are PCB mount relays, although custom options may be available on request.
Key Features:
D Size Form C (Changeover) Relay
100 W Switching Power
Changeover Contacts
UL Approved
PCB Mount
Available With or Without Magnetic Screen
Switch Action: SPCO
Contact Material: Tungsten
Isolation Across Contacts DC or AC: 0.75 kV Peak
Isolation Contact to Coil DC or AC: 3 kV Peak
Max. Switching Power: 100 VA Resistive (@ 33.3 VDC Switching Voltage)
Max. Switching Voltage: 240 VDC (@ 20 VA Switching Power)
Max. DC Switching Current: 3 A (@ 100 VA Switching Power and 33 VDC Switching Voltage)
Max. DC Carry Current: 4 A
Capacitance Across Contacts: 2.3 pF (Coil to Screen Grounded)
Max. Contact Resistance. 500 mΩ (Typical)
Min. Insulation Resistance: 108 Ω (Rypical) (108 )
Coil Voltage: 5 V, 12 V, 24 V
Must Operate Voltage: 3.75 VDC , 9 VDC, 18 VDC
Must Release Voltage: 0.5 VDC, 1.2 VDC, 2.4 VDC
Resistance (±10%): 50 Ω, 340 Ω, 900 Ω
Product number:
SW11851
Manufacturer:
D200 Series HV Reed Relays
200 W High Voltage Relay
The D200 series combines a high power 200W switching capacity with isolation of 7kV across the contacts. This switching performance is achieved through the use of high vacuum reed switches with Tungsten contacts and make these relays suitable for high reliability applications, such as test equipment and high voltage power supplies.
Product number:
SW10209
Manufacturer:
DA Series HV Reed Relays
The DA(UL) series of high-voltage reed relays is UL approved. Very high isolation voltages (up to 10 kV) are achieved through the use of high-vacuum reed switches with either rhodium or tungsten contacts and make these relays suitable for high reliability applications, such as cardiac defibrillators, test equipment and high-voltage power supplies.
A choice of 5 kV, 7.5 kV and 10 kV isolation voltages is available. The rhodium contact relays have low contact resistance, while the tungsten contact relays can switch higher voltages. PCB or panel mount, via nylon studs, versions are available. Connection options for the HV include PCB, solder turret (wire wrap), flying lead and 0.25” spade terminals.
Key Features:
UL Approved, Normally Open, High Voltage Relays
Choice of 10 kV, 7.5 kV or 5 kV Isolation
Low Contact Resistance
PCB or Panel Mount
HV Connections via Flying Leads, Solder Turret (Wire Wrap), or 1/4” Spade Terminals
Excellent AC Characteristics
Product number:
SW11852
Manufacturer:
DB Series HV Reed Relays
The DB(UL) series of high-voltage reed relays is UL approved. Very high isolation voltages (up to 10 kV) are achieved through the use of high vacuum reed switches with either rhodium or tungsten contacts and make these relays suitable for high reliability applications, such as cardiac defibrillators, test equipment and high-voltage power supplies.
A choice of 5 kV, 7.5 kV and 10 kV isolation voltages is available. The rhodium contact relays have low contact resistance, while the tungsten contact relays can switch higher voltages, up to 7000 V DC/AC peak. PCB or panel mount, via nylon studs, versions are available. Connection options, for the HV, include PCB, solder turret (wire wrap), flying lead and 0.25” spade terminals.
Key Features:
UL Approved, Normally Open, High Voltage Relays
Choice of 10 kV, 7.5 kV or 5 kV Isolation
Low Contact Resistance
PCB or Panel Mount
HV Connections via Flying Leads, Solder Turret (Wire Wrap), or 1/4” Spade Terminals
Excellent AC Characteristics
Product number:
SW11853
Manufacturer:
