ThermoWrap

The ThermoCube PAO is a compact, ultra-reliable thermoelectric chiller designed for precision temperature control using PAO (Poly-Alpha-Olefin) fluids. Engineered by Solid State Cooling Systems, this refrigerant-free solution delivers vibration-free cooling performance with ±0.1°C stability—even near ambient temperatures. With a cooling capacity of 275 watts and a rugged stainless steel construction, ThermoCube PAO is ideal for avionics, aerospace, and other point-of-use applications where leak-free operation and high reliability are essential.Built on a foundation of thermoelectric modules rated for over 200,000 hours of operation, the ThermoCube PAO eliminates the need for compressors or facility chilled water. It features universal power input and variable voltage control, drawing only the power required to maintain set temperatures. Whether you're bench testing avionics or cooling airborne electronics, ThermoCube PAO delivers consistent thermal performance in a compact 13” x 11” x 13” (33 cm x 28 cm x 33 cm) footprint.Key featuresPrecision thermal control: Maintains fluid temperatures with ±0.1°C repeatability, even near ambient conditions.Refrigerant-free operation: Uses solid-state thermoelectric technology for quiet, vibration-free cooling without harmful refrigerants.275-watt cooling capacity: Delivers reliable performance at 20°C ambient, ideal for high-demand applications.Leak-free design: All stainless steel tank and plumbing with Swagelok fittings ensure long-term durability and fluid containment.High-pressure pumps: Magnetically coupled gear pumps deliver up to 45 psig, supporting avionics and other pressure-sensitive systems.Fluid compatibility: Optimized for PAO fluids, with options available for Fluorinert, Galden, or HFE.Smart power management: Variable voltage control minimizes energy consumption by adjusting power draw based on thermal load.External fluid filter: Includes a 5 μm filter with grounding strap to maintain fluid purity and system integrity.Compact and portable: Weighs just 34 lbs (15.4 kg) and fits easily into benchtop or rack-mounted setups.Universal power input: Operates on 115–230 VAC, 50/60 Hz, for global compatibility.User-friendly interface: Controlled via keypad or RS232, with alarms for temperature, fluid level, and system faults.Certified safe:TUV listed to UL, CAN/CSA, EN 61010-1, and CE standards.Warranty: Backed by a 2-year manufacturer warranty.ApplicationsThermoCube PAO is trusted by customers across industries for its reliability and precision:Avionics bench testing: Provides stable cooling for sensitive electronics during ground-based testing.Airborne cooling: Supports in-flight thermal regulation for mission-critical systems.Power supply cooling: Maintains optimal operating temperatures for high-performance power electronics.Point-of-use temperature control: Ideal for localized cooling in research labs, industrial setups, and defense applications.What's next?As industries demand more compact, efficient, and environmentally responsible cooling solutions, Solid State Cooling Systems continues to lead the way. The ThermoCube PAO exemplifies this commitment, offering a rugged, high-precision chiller tailored for PAO-based systems. With its proven reliability and advanced features, it’s the go-to choice for aerospace, defense, and industrial professionals.To learn more or request a quote, contact us and discover how ThermoCube PAO can meet your temperature control needs.

Wavelength Range 1.0-5.0 µm MWIR; Detector Size 1x1, 2x2 mm; Time Constant <2 µs; Responsivity 9x103, 4.5x103 V/W; Element Resistance 0.1-2.0 MΩ New Infrared Technologies’ (NIT) LEPTON Series of single-pixel VPD PbSe MWIR detectors are available uncooled as well as with integrated TECs (thermoelectric cooling elements), with different geometries, packaging solutions and preamplifier boards. LEPTON Series single-pixel detectors come in two standard sizes: 1 mm × 1 mm or 2 mm × 2 mm. LEPTON Series uncooled single-pixel PbSe MWIR detectors can be ordered packaged in SMD or TO-5 housings (with cap, hermetic) with sapphire window. These detectors are operational at room temperature and don’t require any cooling devices. LEPTON Series cooled single-pixel PbSe MWIR detectors are hermetically packaged in a TO-8 can housing with cap and sapphire window and include one or two thermoelectric cooler (TEC) stages for higher sensitivity as well as a thermistor. A calibration curve for the thermistor is available. NIT’s LEPTON Series also includes two low-noise preamplifier boards that are 5-V-powered via mini-USB connector: The LEPTON ANALOG PREAMP provides rotary switches to manually select the detector biasing voltage (4 steps from 1.25 V to 10 V) as well as the transimpedance gain (4 steps from 104 to 107 V/A). This preamp outputs a ±10 V analog voltage on a BNC connector. The LEPTON PREAMP WITH USB OUTPUT allows to digitally select the values for detector biasing voltage and transimpedance gain via software. Here, the output is a digital 14 Bit signal with a maximum sampling rate of 20 ksps. This preamp also features an analog output for the preamplifier stage on SMB or BNC connector. For more pixels, linear and two-dimensional array MWIR cameras are available from New Infrared Technologies – please refer to the LUXELL series of linear array MWIR cameras and TACHYON series of high-speed imaging MWIR cameras respectively. Key Features: Detector Sensing Material: VPD Polycrystalline PbSe Uncooled and TEC-cooled (1-stage, 2-stages) Versions Available Square Pixels, Available Pixel Geometries: 1 x 1 mm, 2 x 2 mm Packaging: SMD (10x10 mm) Non-hermetic, TO-5 (9.14 mm Dia.) Hermetic With Cap, TO-8 (15.24 mm Dia.) Hermetic With Cap Sapphire Window IR Detection Band: MWIR, 1.0 µm to 5.0 µm Peak Wavelength of Detection: 3.7 µm D* (λpeak) Uncooled: 2x109 Jones Typical D* (λpeak, 1,000 Hz, 1.2 Hz) Cooled: 1x1010 Jones Time Constant: <2 µs Biasing Voltage: 5 V, 10 V Typical Element Resistance: 0.1 to 2.0 MΩ Responsivity (@Vb = 10 V): 9x103 V/W (1x1 mm), 4.5x103 V/W (2x2 mm) Power: 1 mW Read-out Electronics External (Not Included) Customizable Operating Temperature: +5 °C to +70 °C (SMD), -40 °C to +85 °C (TO-5, TO8) Amplifier Board Transimpedance Gain: 104 to 107 V/A, Adjustable Manually or per Software Amplifier Board Dark Current Cancellation: 1.24 µA to 1 mA, Adjustable Manually or per Software Amplifier Board Power Supply: 5 VDC, 60 mA (mini-USB Connector) Amplifier Board Output: Analog (±10 V), Digital (14 Bit) Amplifier Board Noise: 5 pA @1 kHz, 107 V/A Amplifier Board Dimensions: 75.90 x 35.10 x 28.70 mm (Analog), 89.30 x 35.10 x 26.30 mm (USB Output) Applications: Gas & Flame Detection; Laser Detection

The ThermoCube II 650 is the newest addition to Solid State Cooling Systems’ renowned ThermoCube line, delivering enhanced thermal performance in a compact, energy-efficient design. With 650 watts of cooling capacity and ±0.05°C temperature stability, this benchtop thermoelectric chiller is engineered for precision, reliability, and versatility across a wide range of scientific and industrial applications.Built on the proven architecture of the ThermoCube II series, the 650 model introduces a redesigned power subsystem, a more powerful controller, and expanded software capabilities. It offers 30% more cooling capacity than previous models while maintaining the same height and width, making it a plug-and-play upgrade for existing setups. With over 35,000 ThermoCube units sold globally, the ThermoCube II 650 continues the legacy of world-class reliability and ease of use.Key featuresHigh-capacity cooling: Provides 650 watts of cooling at 20°C ambient with an aluminum cold plate, ideal for demanding thermal control tasks.Exceptional precision: Maintains temperature stability within ±0.05°C at constant load, ensuring consistent performance.Compact footprint: Measures just 11” x 14.5” x 13” (28 x 37 x 33 cm), fitting easily into benchtop environments.Quiet operation: Operates at <50 dBA at 50% load and <63 dBA at full load, minimizing noise in sensitive settings.Flexible pump options: Supports centrifugal and gear pumps, including a new high-performance 5 lpm (5G) gear pump.Versatile fittings: Compatible with 1/4” or 3/8” (0.6 cm or 0.3 cm) fittings including John Guest, CPC, APC, swage, or FNPT.Advanced connectivity: Offers RS232, RS485, Ethernet, and TTL communication protocols for seamless integration.Smart features: Includes variable speed fan and auto-restart as standard, plus alarms for temperature, fluid level, and system failures.Wide operating range: Standard range of 5°C to 50°C, with optional extensions down to -5°C (LT) and up to 65°C (HT).Durable construction: Wetted materials include aluminum, copper, or stainless steel, with a 300 ml tank and level sensor.Universal power input: Operates on 100–240 VAC, 50/60 Hz, suitable for global deployment.Certified and safe: TUV listed to UL, CAN/CSA, EN 61010-1, CE 61010-1, and RoHS compliant.Warranty: Backed by a 2-year warranty for peace of mind.ApplicationsThe ThermoCube II 650 is ideal for a broad spectrum of temperature-sensitive environments:Laboratory research: Supports precise thermal control for experiments, sample preservation, and analytical instruments.Bioprocessing: Maintains stable conditions for biological reactions, fermentation, and fluid handling.Semiconductor manufacturing: Enables accurate cooling for MOCVD, etching, and deposition processes.Medical and life sciences: Regulates temperature for diagnostic devices, reagents, and biological samples.Industrial systems: Cools lasers, optics, and other heat-sensitive equipment with precision and reliability.What's next?Solid State Cooling Systems continues to lead the way in thermoelectric innovation, offering scalable, eco-friendly solutions for modern thermal management. The ThermoCube II 650 exemplifies this commitment, combining increased capacity, intelligent features, and compact design to meet the evolving needs of science and industry.To explore configuration options or request a quote contact AMS Technologies.

Back-illuminated sCMOS; Resolution 2048x2048 pixels; Maximum Frame Rate @ Full Resolution 40 fps; Maximum Pixel Rate 184 Mpixel/s; Maximum Dynamic Range 26,667:1, Shutter Type: Rolling Shutter; Sensor Cooling passiveUtilizing sCMOS technology, the pco.panda 4.2 bi is a back-illuminated camera boasting a remarkable quantum efficiency of up to 95%. This feature renders the camera exceptionally suitable for demanding low-light imaging applications, eliminating the necessity for active cooling. Equipped with a 2048 x 2048 pixel sCMOS sensor and a 6.5 x 6.5 μm pixel size, our ultra-compact pco.panda 4.2 bi ensures enhanced detail, resulting in high-quality images.Key features: USB 3.1 interface for faster data transfer and operation without external PSUIdeal for low-light applications Ultra-compact packaging for a variety of applicationsApplications: Various microscopy and life science applicationsPlease note that Excelitas products are available from us only in Denmark, Finland, Iceland, Norway, and Sweden.
