ThermoCube II 650

Output Current TEC ±10, ±15 A; Benchtop or Rack Mount; Supply Voltage 100-240 VAC; USB, Ethernet Communication Interface; Temperature Stability 0.0009°CWavelength Electronics’ TC LAB series of instrument type temperature controllers integrates high-end digital control with a precision output current drive stage to offer the best stability temperature control instrument commercially available today. Many different sensors can be used in the feedback loop including thermistors, RTDs, linear current and voltage sensors. Within the TC LAB series, two models are available driving a thermoelectric or resistive heater with maximum currents of 10 A (TC10 LAB) with 15 V compliance or 15 A maximum (TC5 LAB) with 20 V compliance. The advanced and reliable circuitry of the TC LAB series instruments achieves better than 0.0009 °C temperature stability with thermistors. Safety features protect the thermoelectric cooler [TEC] and its load. Over and under temperature limits as well as positive and negative current limits can be set. If the sensor signal is lost or a short is detected at the TEC, output current is disabled. If temperature limits are exceeded, a signal to the active load can be sent to disable its current. For example, connect the LD Shutdown BNC output to the Active Lock input on Wavelength Electronics’ QCL LAB driver, and the QCL current will shut down if temperature limits are exceeded. An auxiliary sensor can be used to monitor the temperature of the system heatsink. With Wavelength’s plug and play instrument, you have the ability to quickly set the controls using either the instrument touch screen or a remote computer, and results are easy to monitor. This allows taking your temperature-controlled application from the test bench to market quickly and efficiently. Wavelength Electronics’ proprietary IntelliTune® algorithm characterizes the TEC/sensor system’s response to the controller and determines the optimal PID control coefficients. It then automatically adjusts the PID control values as setpoint, tuning mode, or bias current change. Run IntelliTune® easily just off ambient and watch it change PID settings for a much higher or lower setpoint. After a single scan, explore either optimized setpoint response or disturbance rejection performance with your load to see which works best. Add or remove the D term to see if noise is an issue. IntelliTune® lets you skip the manual characterization and it’s smart enough to really work—very little adjustment is needed after you have stored a successful characterization scan. See Application Note IntelliTune® vs. Conventional Autotune for an in-depth exploration. One mating DB 15+2 thermoelectric and sensor plug is included with the instrument. As accessories, various further devices are available, like a DB9 mating connector for status/enable signals, a DB15+2 male connector with hood and high current pin inserts, full cables for the DB9 and DB15+2 or single and dual rack mount kits. When controlling laser diode temperature, the LDMOUNT-5A, a 14-pin butterfly laser diode mount with integrated heat sinking, is available for simple connections between the instrument and the laser. If you need a lower power temperature control instrument, consider the LFI3751 series. Free, effective and responsive technical support is available to simplify integration of Wavelength products into your OEM design. Standard products can be easily modified to meet your application requirements. Get in touch with the AMS Technologies laser diode driver experts to discuss your customized solution! Key Features: Instrument Type, Benchtop Use Size: 89 x 221 x 450 mm 19" Rack Mountable, 2 U Half Rack Output Current up to ±15 A Supply Range: 100 to 240 VAC (±10%), 3A, 50 to 60 Hz Compliance Voltage 20 V Compatible With Most Sensor Types (Thermistor, RTD, IC, IR) Temperature Stability Better than 0.0009 °C Intuitive User Interface Touchscreen IntelliTune® PID Control, Setpoint Response or Disturbance Rejection Optimization Adjustable Current Limits Over- and Under-temperature Protection USB, Ethernet Interfaces Applications: Research in Electro-optical, Medical, Spectroscopy and Defense Systems; Communications; Manufacturing; Particle and Droplet Measurement; Manufacturing Test; Airborne Instrumentation; Spectroscopic Monitors; Medical Diagnostic Equipment

The ThermoCube PAO is a compact, ultra-reliable thermoelectric chiller designed for precision temperature control using PAO (Poly-Alpha-Olefin) fluids. Engineered by Solid State Cooling Systems, this refrigerant-free solution delivers vibration-free cooling performance with ±0.1°C stability—even near ambient temperatures. With a cooling capacity of 275 watts and a rugged stainless steel construction, ThermoCube PAO is ideal for avionics, aerospace, and other point-of-use applications where leak-free operation and high reliability are essential.Built on a foundation of thermoelectric modules rated for over 200,000 hours of operation, the ThermoCube PAO eliminates the need for compressors or facility chilled water. It features universal power input and variable voltage control, drawing only the power required to maintain set temperatures. Whether you're bench testing avionics or cooling airborne electronics, ThermoCube PAO delivers consistent thermal performance in a compact 13” x 11” x 13” (33 cm x 28 cm x 33 cm) footprint.Key featuresPrecision thermal control: Maintains fluid temperatures with ±0.1°C repeatability, even near ambient conditions.Refrigerant-free operation: Uses solid-state thermoelectric technology for quiet, vibration-free cooling without harmful refrigerants.275-watt cooling capacity: Delivers reliable performance at 20°C ambient, ideal for high-demand applications.Leak-free design: All stainless steel tank and plumbing with Swagelok fittings ensure long-term durability and fluid containment.High-pressure pumps: Magnetically coupled gear pumps deliver up to 45 psig, supporting avionics and other pressure-sensitive systems.Fluid compatibility: Optimized for PAO fluids, with options available for Fluorinert, Galden, or HFE.Smart power management: Variable voltage control minimizes energy consumption by adjusting power draw based on thermal load.External fluid filter: Includes a 5 μm filter with grounding strap to maintain fluid purity and system integrity.Compact and portable: Weighs just 34 lbs (15.4 kg) and fits easily into benchtop or rack-mounted setups.Universal power input: Operates on 115–230 VAC, 50/60 Hz, for global compatibility.User-friendly interface: Controlled via keypad or RS232, with alarms for temperature, fluid level, and system faults.Certified safe:TUV listed to UL, CAN/CSA, EN 61010-1, and CE standards.Warranty: Backed by a 2-year manufacturer warranty.ApplicationsThermoCube PAO is trusted by customers across industries for its reliability and precision:Avionics bench testing: Provides stable cooling for sensitive electronics during ground-based testing.Airborne cooling: Supports in-flight thermal regulation for mission-critical systems.Power supply cooling: Maintains optimal operating temperatures for high-performance power electronics.Point-of-use temperature control: Ideal for localized cooling in research labs, industrial setups, and defense applications.What's next?As industries demand more compact, efficient, and environmentally responsible cooling solutions, Solid State Cooling Systems continues to lead the way. The ThermoCube PAO exemplifies this commitment, offering a rugged, high-precision chiller tailored for PAO-based systems. With its proven reliability and advanced features, it’s the go-to choice for aerospace, defense, and industrial professionals.To learn more or request a quote, contact us and discover how ThermoCube PAO can meet your temperature control needs.
