TSF70 Series Horizontal Float Switches
Product number:
SW11847
Manufacturer:
Cynergy 3 Components-Sensata Technologies
Product information "TSF70 Series Horizontal Float Switches"
The TSF70 series is a compact external fitting device, with a high specification thermistor so capable of sensing both liquid level and temperature. Mounting of this series is with the use of a compression seal, so does not require access to the inside of the tank.
Typical applications include vending machines, commercial washing machines and evaporator units. The level switches are manufactured in a variety of materials with a choice of gasket materials, to suit most commonly used liquids. The switch action may be reversed by rotating the device through 180º.
Key Features:
- Compact External Mount with Temperature Sensing
- Available in Nylon, Polypropylene or PPS
- 25 VA & 100 VA Versions
- WRAS Approved Versions
Manufacturer "Cynergy 3 Components-Sensata Technologies"
