S2 Series HV Reed Relays
Product number:
SW11854
Manufacturer:
Cynergy 3 Components-Sensata Technologies
Product information "S2 Series HV Reed Relays"
The S2(UL) reed relay series from Cynergy3 - Sensata has been developed for applications where PCB mounting is not possible. The relays can be mounted using a variety of methods and orientations to suit particular applications. The terminal pins are flexible enough to allow bending for assembly into equipment.
Available with either a 10 W or 50 W contact in a pressurized reed switch or a 100 VA contact in a vacuum reed switch.
Key Features:
- UL Approved
- Axial Style Reed Relay
- Variable Mounting Options
- 10 W, 50 W and 100 VA Contact Options
- Reliable Reed Switch Contacts
