Plastic Molded Si Photodiodes
Product information "Plastic Molded Si Photodiodes"
350 to 1100 nm; Active Area 0.81 to 16 mm2; AA Dia. 1.02 Round, 2.31 x 1.68 to 4.00 x 4.00 mm Rect.; Rise Time 11 to 100 ns; Responsivity 0.15 to 0.55 A/W; Capacitance 2 to 330 pF; Package Leadless Ceramic, Resin Molded, Plastic Molded
OSI Optoelectronics offers a line of high quality and reliability plastic encapsulated photodiodes. These molded devices are available in a variety of shapes and sizes of photodetectors and packages, including industry standard T1 and T13/4, flat and lensed side lookers as well as a surface mount version (SOT-23). They are excellent for mounting on PCB and hand-held devices in harsh environments.
They have an excellent response in the NIR spectrum and are also available with visible blocking compounds, transmitting only in the 700-1100 nm range. They offer fast switching time, low capacitance as well as low dark current. They can be utilized in both photoconductive and photovoltaic modes of operation.
Key Features:
- High-density & Rugged Molded Package
- Low Capacitance
- Low Dark Current
Applications: Bar Code Readers; Measurement & Control; IR Remote Control; Reflective Switches
