MZI-001 Mach-Zehnder Interferometer

Designed for Production Environment; Manual or Autofocus; Field of View 0.7 x 0.5 mm; Measurement Speed 0.5 s; Output USB 2.0; Connector Type LC, SC, SMA Data-Pixel’s 3D SCOPE-V2 series of interferometers for single-fiber connectors have been specifically designed for use in a production environment. These interferometers are robust, compact and easy to use tools that bring speed and precision to operators. 3D SCOPE-V2 interferometers are available in two versions with manual focus or autofocus. The 3D Scope-V2 interferometers support Data-Pixel’s BLINK software platform (included). Non-compressed, real-time and high-quality images are transferred from the hardware to the software via a USB 2.0 link in addition to the automation and control commands. 3D SCOPE-V2 interferometers are compatible with Data-Pixel’s SUPERVISOR software, a MES style software which is in charge of the execution, management and monitoring of the production in an assembly workshop for fiber optic connectors. Its role is to supervise machines and help operators with complete traceability of the manufacturing information. The 3D SCOPE-V2 interferometers are fully compliant with industry standards. Key Features: Measurement of PC and APC Connectors, Ferrules and Bare Fibers Lightning Speed Measurement Cycle (0.5 s) PASS/FAIL Result Visual Feedback Via Front Panel Start-button LED Color Integrated PC/APC Tilt Stage, no APEX Re-calibration Required True Phase-shifting Interferometers Vibration Insensitive Autofocus Option Compliance with Industry Standards for Interferometer Measurements Intuitive BLINK Software With Data-base Connectivity Measurement Report in HTML Format Compatible With Desktop PC, Laptop, Tablet PC Applications: Measuring End-face Geometry of Single-Fiber Connectors

Cost Effective; Field of View 3.3 x 2.7, 5.6 x 3.0 mm; Measurement Speed <5 s (+ calcul.); Output USB 3.0, 2.0; Connector Type MT 12/24, MT 16/32 (Male, Female, Ferrule), MPO 12/24, MPO 16/32 With DAFFI MT, Data-Pixel has developed a series of cost effective interferometers for multi-fiber connectors, suitable for high volume production without compromising accuracy or performance. Two versions are available, supporting MT-12 (DAFFI MT12) or MT-16 (DAFFI MT16) multi-fiber connectors. Based on Data-Pixel’s extensive interferometer manufacturing experience, the supplier designed the DAFFI MT interferometers to be robust, fast and accurate in order to meet all requirements of manufacturing or laboratory environments. With Data-Pixel’s BLINK software platform (included), DAFFI MT interferometers are able to measure the end face geometry on multi-fiber connectors and ferrules. The DAFFI MT interferometer accessories (flange and adapters) are fully compatible with the DAFFI SF, DAISI V3, DAISI MT FP and DAISI MT-V3 interferometers, allowing the user to limit the costs of the 3D geometry measurement units. DAFFI MT interferometers are compatible with Data-Pixel’s SUPERVISOR software, a MES style software which is in charge of the execution, management and monitoring of the production in an assembly workshop for fiber optic connectors. Its role is to supervise machines and help operators with complete traceability of the manufacturing information. Key Features: Measures PC APC Connectors and Ferrules True Phase-shifting Interferometer Non-contact Measurement Smart Autofocus, Focus Only When Required Automatic Calibration of Reference Mirror Supports MT-16 and MT-12 (DAFFI MT16 or DAFFI MT12) Vibration Insensitive Easy and Fast Switching From PC to APC, no Change of Fiber Holder Required Compliance with Industry Standards for Interferometer Measurements Intuitive BLINK Software With Data-base Connectivity Compatible with Desktop PC, Laptop, Tablet PC Applications: Measuring End-face Geometry of Multi-Fiber Connectors

Cost Effective; Field of View 1.1 x 0.9 mm; Measurement Speed 1 s; Output USB 3.0, 2.0; Connector Type LC, MU, SC, FC, SMA, E2000 Data-Pixel’s DAFFI SF interferometer for single-fiber connectors is a cost effective solution for high volumes production, without compromising on accuracy or performance. Based on Data-Pixel’s extensive interferometer manufacturing experience, the supplier designed the DAFFI SF interferometer to be robust, fast and accurate in order to meet all requirements of manufacturing or laboratory environments. With the BLINK software platform, DAFFI SF interferometers are able to measure the end face geometry on single fiber connectors in a very short time. The DAFFI SF interferometer accessories (flange and adapters) are fully compatible with the DAFFI MT, DAISI V3, DAISI MT FP and DAISI MT-V3 interferometers, allowing the user to limit the costs of the 3D geometry measurement units. DAFFI SF interferometers are compatible with Data-Pixel’s SUPERVISOR software, a MES style software which is in charge of the execution, management and monitoring of the production in an assembly workshop for fiber optic connectors. Its role is to supervise machines and help operators with complete traceability of the manufacturing information. Key Features: Measurement of PC and APC Connectors, Ferrules and Bare fibers True Phase-shifting Interferometer Non-contact Measurement Smart Autofocus, Focus Only When Required Servo-controlled Reference Mirror for Automatic Apex Calibration Vibration Insensitive Easy and Fast Switching From PC to APC, no Change of Fiber Holder Required Compliance with Industry Standards for Interferometer Measurements Intuitive BLINK Software With Data-base Connectivity Compatible with Desktop PC, Laptop, Tablet PC Applications: Measuring End-face Geometry of Single-Fiber Connectors

Microscope (x 400) Included; Field of View 0.7 x 0.5 mm; Measurement Speed 1 s; Output USB 2.0; Connector Type LC, PC, MU, SC, FC, SMA, E2000 Data-Pixel’s DAISI MT FP interferometer for multi-fiber connectors combines the DAISI MT-V3 series interferometer with the new “Floating Pastille” fixture technology from Data-Pixel (patent pending). This major technological breakthrough for multi-fiber connector fixtures is perfectly suited for highly accurate X/Y endface angle measurements. With the Floating Pastille fixtures, measurement results are completely independent from the influence of the fiber optic cables and the operator. Floating Pastille is perfectly suitable for the inspection of connectors mounted with heavy cables. With the help of the Floating Pastille, the DAISI MT-V3 is now easier to operate, without compromising any of its existing features like accuracy of measurements, reproducibility, speed or robustness. No calibration is now required, as it is factory set, per fixture, by Data-Pixel. With Data-Pixel’s BLINK software (included), operators have the easiest way to produce customised control reports. The DAISI MT FP interferometer is compatible with Data-Pixel’s SUPERVISOR software, a MES style software which is in charge of the execution, management and monitoring of the production in an assembly workshop for fiber optic connectors. Its role is to supervise machines and help operators with complete traceability of the manufacturing information. Key Features: Combined White-Light and Red-Light Phase-shifting Interferometer for Precise Tip Radius and Core-dip Measurement Fast Autofocus That Simplifies Operator’s Handling Very High Accuracy and Reproducibility for Small X/Y Angles Measurements Suitable for Field Heavy Cables, Standard Small Cables MTP/MPO Connectors and Pigtails With MT Ferrules No Calibration Required Floating Pastille Flange is Compatible With Existing DAISI MT Units Closed-loop High Precision 30 µm Z-Scan Vibration Insensitive High Resolution Optics and Camera for a Better Resolution Large Field of View Able to Scan up to 96 Fibers Applications: Measuring End-face Geometry of Multi-Fiber Connector

Designed for Production and Field; Field of View 5.6 x 3.0 mm; Measurement Speed <5 s (MT12); Output USB 3.0, 2.0; Connector Type MT 12/24, MT 16/32 (Male, Female, Ferrule), MPO 12/24, MPO 16/32 Data-Pixel’s DAISI MT-V3 interferometer for multi-fiber connectors is the industry reference for MT product measurements, based on the same design philosophy that made the DAISI series of interferometers a success. The DAISI MT-V3 interferometer has been designed for use in production and field applications. Recently, the measurement speed has been largely optimized. Measurement plus calculation time is now better than 5 seconds for MT-12 based connectors. With Data-Pixel’s BLINK software platform, DAISI MT-V3 interferometers are able to measure end face geometry on single-fiber or multi-fiber connectors or ferrules. The BLINK software platform is the easiest way to produce customised control reports. DAISI MT-V3 interferometers are compatible with Data-Pixel’s SUPERVISOR software, a MES style software which is in charge of the execution, management and monitoring of the production in an assembly workshop for fiber optic connectors. Its role is to supervise machines and help operators with complete traceability of the manufacturing information. Key Features: Measurement of PC and APC Connectors, Ferrules Suitable for Multi-fiber (MT, MPO, MT-RJ,…) and Single-fiber (2.50mm, 1.25mm,…) True Phase-shifting Interferometer Non-contact Measurement Smart Autofocus, Only Focus When Required Automatic Calibration of Reference Mirror Supports MT-16 and MT-12 Based Connectors Vibration Insensitive Easy and Fast Switching From PC to APC, No Change of Fiber Holder Required Compliance With Industry Standards for Interferometer Measurements Intuitive BLINK Software With Data-base Connectivity Compatible with Desktop PC, Laptop, Tablet PC Applications: Measuring End-face Geometry of Multi-Fiber and Single-Fiber Connectors

Microscope (x 400) Included; Field of View 0.7 x 0.5 mm; Measurement Speed 1 s; Output USB 2.0; Connector Type LC, PC, MU, SC, FC, SMA, E2000 Data-Pixel’s DAISI V3 interferometer for single-fiber connectors provides the ultimate production solution for measuring end-face geometry on single-fiber connectors, equipped with a revolutionary “no-exterior-moving-parts” mechanical design. The unit combines a x400 microscope and an interferometer in order to control connectors after polishing in a very short time. With Data-Pixel’s BLINK software (included), operators have the easiest way to produce customised control reports. DAISI V3 interferometers are compatible with Data-Pixel’s SUPERVISOR software, a MES style software which is in charge of the execution, management and monitoring of the production in an assembly workshop for fiber optic connectors. Its role is to supervise machines and help operators with complete traceability of the manufacturing information. The DAISI-V3 interferometer is fully compatible with industry measurement standards. Key Features: Testing of PC/APC Connectors and Ferrules from 1 to 64 Fibers Ultra-fast Measurement Time Automatic Pass/Fail Defect Analysis Automatic Focus Adjustment High Resolution Optics With a Defect Size Detection of 0.5 μm Compliance with IEC Standards 61300-3-35 Real-time Full Connector Endface View Intuitive BLINK Software Compatible With Desktop PC, Laptop, Tablet PC Applications: Measuring End-face Geometry and Surface Inspection for Single-Fiber Connectors

1064, 1310, 1550 nm; Modulator Constant 0.8-2.5 rad/V; Maximum Voltage Range ±500 V; Fiber Type HI-1060, SMF28e+; Connector Type FC/APC Optiphase, a leading supplier of ultra-high-performance interferometric systems, offers MFI Michelson and MZI Mach-Zehnder fiber interferometers for use in precision test and measurement instrumentation as well as fiber sensing systems. These interferometers are driven by Optiphase’s own PZ1 low-profile fiber stretcher with enhanced modulation, through a front panel BNC connector. MFI Michelson and MZI Mach-Zehnder interferometers are available in wavelengths from 1064 to 1550 nm. Each interferometer has a “zero meter” path mismatch which provides flexibility to change the delay length to match varying test applications. The standard length shipped is 50 m. Optiphase also builds custom interferometers on request, please contact AMS Technologies and let us know of your specific requirements. Key Features: Operating Wavelength: 1064, 1310 , 1550 nm Modulation, Modulator Constant: 0.8 to 2.5 rad/V Maximum Voltage Range: ±500 V (Off Resonance, 1,000 V Peak-to-Peak) Modulator Interface: BNC Path Mismatch (Without Delay): 0 m ±10 cm Fiber Type: HI-1060, SMF28e+ Optical Interface, Connector Type: FC/APC Optical Power Limit: 250, 500 mW Delay Coil Length Range: 0.5 to 1,000 m, 50 m Standard Dimensions: 10.2”L X 6.3”W X 3.5H Applications: Laser Phase/Frequency Noise Testing; Interferometric Sensor Simulation; Path Imbalance Interferometer; Precision Test & Measurement Instrumentation; Fiber Sensing Systems
