ILT970-BB Broad Band Spectroradiometric Measurement Systems

UV-NIR; 200-1750 nm; Resolution 0.05-50.0 nm; Sensitivity 38,000-665,000 Counts/µW per ms Integration Time; CMOS or InGaAs Array Detector; Interface USB 2.0; 95x68x20 mm Miniature spectroscopy redefined – that's what Avantes considers the CompactLine series spectrometers. The new generation, Avantes’ AvaSpec-Mini MK-II series (AvaSpec-Mini2048CL and AvaSpec-Mini4096CL) is definitely one of the smallest types of spectrometers on the market today. In cases where size matters, the AvaSpec CompactLine family offers spectrometers with the smallest form factor – only the size of a deck of cards. This enables easier integration of Avantes’ spectrometers into machines and handheld devices. Squeezing down the size hardly compromises the performance of the instruments but limits the customer a bit in the number of possible configurations. This instrument with excellent temperature and wavelength stability is easy to take anywhere you like and very well suited for handheld applications. The AvaSpec-Mini-CL series with CMOS detectors and advanced electronics and communications can be equipped with a 2048-pixel CMOS detector (AvaSpec-Mini2048CL) or Avantes’ first-to-the-market 4096-pixel array (AvaSpec-Mini4096CL). And the AvaSpec-Mini-NIR is a compact near-infrared spectrometer with InGaAs detector, based on Avantes’ popular AvaSpec-NIR256-1.7-EVO NIRLine series spectrometer. Enjoy the speed and enhanced native UV/NIR response of CMOS with an incredible resolution of up to 0.09 nm unavailable anywhere else. The low stray light design allows stray light levels from as low as 0.2% and the fast response time boasts data transfer speeds as fast as 4.6 ms/scan and integration times ranging from 30 to 50 s. Customization is possible when adequate volumes are needed. This makes the CompactLine especially suited for OEM users wanting to integrate a spectrometer into their own devices. To learn more about all the available options and to find the perfect setup that matches your needs, please contact AMS Technologies to discuss your wishes with our sales engineers. The possibilities are virtually endless! For customers with urgent needs and general flexibility in their specifications, Avantes keeps a variety of preconfigured AvaSpec-Mini-CL series CompactLine spectrometers in stock so they are readily available within a significantly decreased shipping time. All preconfigured spectrometers are available at discount pricing (as opposed to custom models) and include an upgrade to AvaSoft-Full. Available preconfigured models are: AvaSpec-Mini2048CL-U25: 2048 Pixels, Grating-MN1200-0.25 (200 to 450 nm), DCL200, 25 µm Slit AvaSpec-Mini2048CL-V25: 2048 Pixels, Grating-MN600-0.50 (350 to 885 nm), DCL200, OSC, OSF305, 25 µm Slit AvaSpec-Mini2048CL-I25: 2048 Pixels, Grating-MN600-1.00 (600 to 1100 nm), DCL200, OSF600, 25 µm Slit AvaSpec-Mini2048CL-UVI25: 2048 Pixels, Grating-MN300-0.3 (200 to 1100 nm), DCL200, OSC-UA, 25 µm Slit AvaSpec-Mini2048CL-VI25: 2048 Pixels, Grating-MN300-0.50 (360 to 1100 nm), DCL200, OSC, OSF305, 25 µm Slit AvaSpec-Mini4096CL-U10: 4096 Pixels, Grating-MN1800-0.25 (200 to 365 nm), DCL200, 10 µm Slit AvaSpec-Mini4096CL-V10: 4096 Pixels, Grating-MN600-0.50 (350 to 885 nm), DCL200, OSC, OSF305, 10 µm Slit AvaSpec-Mini4096CL-I10: 4096 Pixels, Grating-MN600-1.00 (600 to 1100 nm), DCL200, OSF600, 10 µm Slit AvaSpec-Mini4096CL-UVI10: 4096 Pixels, Grating-MN300-0.3 (200 to 1100 nm), DCL200, OSC-UA, 10 µm Slit AvaSpec-Mini4096CL-VI10: 4096 Pixels, Grating-MN300-0.50 (360 to 1100 nm), DCL200, OSC, OSF305, 10 µm Slit Key Features: Optical Bench: Symmetrical Czerny-Turner, 75 mm Focal Length Available Gratings: 300 to 3600 lines/mm Available Slit Sizes: 10 to 500 µm Wavelength Range: 200 to 1750 nm Resolution: 0.05 to 50 nm, Depending on Configuration Stray Light: 0.2% to 1% Sensitivity: 38,000 to 665,000 Counts/µW per ms Integration Time Detector: CMOS Linear Array, 2048 or 4096 Pixels; InGaAs Array, 256 Pixels (AvaSpec-Mini-NIR) Signal/Noise: 300:1 to 5000:1 A/D Converter: 16 Bit, 500 kHz or 6 MHz Integration Time: 10 µs to 50 s Interface: USB 2.0 Sample Speed With Store to RAM or On-board Averaging: 0.53 to 6.5 ms per Scan Data Transfer Speed: 1.2 to 8.9 ms/Scan Dimensions: 95 x 68 x 20 mm Applications: Handheld Instruments; Integration into OEM Machines and Handheld Devices; Food Analysis, Recycling

NIR; 900-2500 nm; Resolution 1.7-85 nm; Sensitivity 26,600-8,200,000 Counts/µW per ms Integration Time; InGaAs Linear Array Detector; Interface USB 2.0, USB 3.0, Gigabit Ethernet; 95x68x20-185x160x 184 mm Instruments in Avantes’ AvaSpec NIRLine are high-performance, near-infrared spectrometers that are optimized for the demands of measuring long wavelengths. This line provides leading-edge performance for dispersive NIR instruments with toroidal focusing mirrors and dynamic dark correction for enhanced stability. The NIRLine series is comprised of both thermoelectrically cooled and uncooled instruments. The AvaSpec-NIR256/512-1.7 features an uncooled 256 or 512 pixel InGaAs detector. All other instruments in the NIRLine have thermoelectric, Peltier-cooled InGaAs detectors which support cooling down to -25 °C against ambient. The AvaSpec NIRLine instruments are fully compatible with Avantes’ AvaSpec StarLine and AvaSpec SensLine spectrometers. Instruments in the NIRLine are available as lab instruments or OEM modules for integration into customers' existing systems. Avaspec NIRLine spectrometers are available with a number of premium options such as irradiance/intensity calibration and non-linearity calibration. Selected models feature the high-sensitivity/low-noise setting: an easy choice between the highest possible sensitivity and the lowest possible noise, right from the AvaSoft 8 software. To learn more about all the available options and to find the perfect setup that matches your needs, please contact AMS Technologies to discuss your wishes with our sales engineers. The possibilities are virtually endless! For measurements in the near-infrared range up to 1.7 µm, Avantes offers the AvaSpec-NIR256/512-1.7-EVO series of affordable, uncooled spectrometers with trusted 256 or 512 pixel InGaAs array detectors. These instruments are USB powered and available with a choice of four gratings and replaceable slit options to match the bandwidth and requirements fitting your application. They feature a sample speed of only 0.53 ms/scan and integration times as fast as 10 µs. For applications where resolution is key, or more datapoints for modelling are required, the 512 pixel detector will be the best choice. If you require optimal noise conditions, even at longer integration times, the cooled versions AvaSpec-NIR256/512-1.7-HSC-EVO are the right choice. Both cooled spectrometers offer the high-sensitivity 100 mm optical bench (HSC) with the next generation of electronics and feature high sample speed and integration times as fast as 20 μs. Did you know the AvaSpec-NIR256-1.7 has a little brother? The AvaSpec-Mini-NIR spectrometer uses the same detector as its bigger counterpart, but in a much smaller package. Like Avantes’ other CompactLine spectrometers, this device is only the size of a deck of cards and USB powered, which makes it easy to integrate into other devices, including but not limited to OEM handheld applications. Since the AvaSpec-Mini-NIR has no moving parts, it is very robust and can be used in virtually any environment! The AvaSpec-NIR256/512-2.5-HSC-EVO series of TEC-cooled NIR spectrometers with replaceable slit are based on a 100 mm optical bench with a numerical aperture (NA) of 0.13, offering optimal balance between resolution and sensitivity. The 2.5-HSC-EVO series feature 256 or 512 pixel InGaAs detectors for wavelengths up to 2,5 µm and are available in multiple configurations. For applications where resolution is key, or more data points for modelling are required, the 512-pixel detector will be the best choice. A range of gratings are available, making it possible to tailor the instruments for optimal performance in your application. In addition to the InGaAs based NIRLine spectrometers, Avantes offers a variety of instruments in the SensLine product family that are ideally suited for the near-infrared (NIR) wavelength region between 800 and 1160 nm – like the AvaSpec-ULS2048XL-EVO , the the AvaSpec-ULS2048x64-EVO or the AvaSpec-ULS2048x16 . These high-sensitivity, low-noise spectrometers employ high quantum efficiency, back-thinned CCD detectors with excellent IR response, offering a more budget-friendly solution for this wavelength range in comparison to the InGaAs array instruments in the NIRline. Avantes offers a wide range of cables to connect your AvaSpec spectrometer to an AvaLight series light source or one of Avantes’ many accessories like fiber optic switches, AvaTrigger, etc. Key Features: Optical Bench: Symmetrical Czerny-Turner With 50/75/100 mm Focal Length Available Gratings: 75 to 600 lines/mm Available Slit Sizes: 25 to 500 µm Wavelength Range: 900 to 2500 nm Resolution: 1.7 to 85 nm, Depending on Configuration Stray Light: ≤1%, Depending on Grating Sensitivity: 26,600 to 8,200,000 Counts/µW per ms Integration Time Detector: InGaAs Linear Array 256 to 512 Pixels, TE Cooled (Except AvaSpec-NIR256/512-1.7) Signal/Noise: 1800:1 to 5000:1 A/D Converter: 16 Bit, 500 kHz to 1.2 MHz Integration Time: 10 µs to 20 s Interface: USB 3.0 High Speed, USB 2.0, Gigabit Ethernet Sample Speed With Store to RAM or On-board Averaging: 0.13 to 0.54 ms per Scan Data Transfer Speed: 0.4 to 1.2 ms/Scan (USB) Dimensions: 95 x 68 x 20, 185 x 84 x 185, 185 x 145 x 185, 185 x 160 x 184 mm Applications: Moisture Content Measurement of Liquids, Solids and Powders for In-line and Quality Control Purposes; Quantitative and Qualitative Measurement of Volatile Organics Such as Ethanol and Methanol; Plastic Characterization and Material Identification; Irradiance Measurements Such as Solar Monitoring; Qualitative Measurements of Feed and Food; Wheat, Grain and Fertilizer Analysis; Dairy Industry; Recycling; Medical; Process Monitoring

UV-NIR; 200-1160 nm; Resolution 0.06-20.0 nm; Sensitivity 250,000-1,200,000 Counts/µW per ms Integration Time; CCD Array Detector; Interface USB 2.0, USB 3.0, Gigabit Ethernet, RS-232; 175x110x44-250x179x144 mm The AvaSpec SensLine series of spectrometers is Avantes’ response to customers who require higher performance for demanding spectroscopy applications such as fluorescence, luminescence and Raman. The AvaSpec SensLine series includes several high-sensitivity, low-noise spectrometers. A number of these instruments feature back-thinned detector technology, of which some are Avantes’ high-performance, thermoelectrically cooled detectors. The other models feature standard CCDs, upgraded to high-performing instruments as a result of Avantes' unique detector cooling technology. The back-thinned CCD detectors featured in the SensLine product family are high quantum efficiency detectors with excellent response in the ultraviolet (UV), visible (VIS) and near-infrared (NIR) range from 200 to 1160 nm. All AvaSpec SensLine instruments are fully integrated with Avantes' modular platform, allowing them to function as both stand-alone and multi-channel instruments. These products are fully compatible with other AvaSpec instruments from Avantes’ StarLine and NIRLine product families. Every instrument in the AvaSpec SensLine series is available as a lab instrument or an OEM module for integration into customers' existing systems. Avantes' innovative ultra-low stray light (ULS), revolutionary high-sensitivity (HS) and the optimal compromise (HSC) optical benches are the core optical technologies in the AvaSpec SensLine. These highly stable optical benches combined with Avantes’ high-performance circuit boards deliver high-performing instruments at affordable prices. To learn more about all the available options and to find the perfect setup that matches your needs, please contact AMS Technologies to discuss your wishes with our sales engineers. The possibilities are virtually endless! The AvaSpec-HERO is built around Avantes’ High-Sensitivity, Compact (HSC), 100 mm optical bench offering a NA of 0.13 and a cooled, back-thinned detector (1024 x 58 pixels). Suitable for use with replaceable slits, this excellent instrument provides the ideal balance between sensitivity and resolution and the capability of using longer integration times in low-light applications, yet ensuring perfect signal-to-noise performance, transferred by the latest communication standards. With its standard, uncooled, 2048 x 64 pixel, back-thinned detector, the AvaSpec-ULS2048x64-EVO spectrometer is perfect for less demanding applications in the UV and NIR range that require integration times lower than 2 s. This spectrometer comes with a wide range of slit sizes and gratings and can be configured with SMA or FC/PC fiber optic entrance connectors. With its back-thinned, 2048 x 64 pixel detector with good sensitivity in the UV and IR region, the AvaSpec-ULS2048x64TEC-EVO enables catching as many photons as possible while the integrated TEC cooling allows long integration times (up to 120 s) with low noise levels. These features make this instrument ideally suited for measuring low-light applications, such as fluorescence or low-light Raman measurements. For high-sensitivity applications where high resolution is not of paramount concern, the AvaSpec-HS2048XL-EVO is an exceptional instrument. Featuring Avantes’ HS optical bench, which has a full 0.22 numerical aperture for superior throughput, this spectrometer has a 14 x 500 µm back-thinned CCD detector with 2048 pixels. The AvaSpec-ULS2048XL-EVO spectrometer combines exceptional quantum efficiency with high-speed communication. Unlike many back-thinned CCD spectrometers with two-dimensional arrays, the ULS2048XL-EVO has large monolithic pixels of 14 x 500 µm with exceptional efficiency in the UV (200 to 400 nm) and NIR (950 to 1160 nm) ranges. The instrument also has an electronic shutter enabling integration times as low as 2 µs. Avantes’ AvaSpec-ULS2048LTEC spectrometers are equipped with a triple-stage thermoelectrically (TEC) cooling, keeping the detector at an optimal +5 °C (maximum -35 °C difference from ambient temperature). The detector cooling provides a significantly lower and more stable dark baseline and PRNU level, dark noise is reduced by a factor of 2 to 3. Thus, the ULS2048LTEC can be used in very low light conditions, such as fluorescence and Raman measurements. Integration times of more than 5 s are possible. The AvaSpec-ULS2048x16 is the best option when looking for a cost-effective, highly sensitive spectrometer. The back-thinned detector features a SNR of 500:1 and a quantum efficiency of up to 78%. Options include a filter to reduce second-order effects and purge ports for deep-UV measurements. The AvaSpec-ULS2048x16 comes with a wide range of slit sizes, gratings and may be configured with SMA or FC/PC fiber optic entrance connectors. Sometimes a single channel spectrometer is not enough, for example when you want higher resolution or to perform two redundant measurements at the same time. The AvaSpec dual channel spectrometers are designed specifically for this purpose. Each spectrometer can be configured independently. It is also possible to have different detector types in each channel. Please contact AMS Technologies to configure the perfect solution for your application. Avantes offers a wide range of cables to connect your AvaSpec spectrometer to an AvaLight series light source or one of Avantes’ many accessories like fiber optic switches, AvaTrigger, etc. Key Features: High Stability High Sensitivity High-speed Acquisition Low Noise Optical Bench: ULS Symmetrical Czerny-Turner With 75 mm Focal Length, High-sensitivity Asymmetrical/Symmetrical Design With 37.5/100 mm Focal Length and 0.22/0.13 NA Available Gratings: 300 to 3,600 lines/mm Available Slit Sizes: 10 to 500 µm Wavelength Range: 200 to 1160 nm Resolution: 0.06 to 20.0 nm, Depending on Configuration Stray Light: 0.04% to <1.0%, Depending on Grating Sensitivity: 250,000 to 1,250,000 Counts/µW per ms Integration Time Detector: CCD Array Image Sensor 1024 to 2048 Pixels, Some Models TE Cooled Signal/Noise: 300:1 to 1200:1 A/D Converter: 16 Bit, 250 kHz to 2 MHz Integration Time: 2 µs to 10 min Interface: USB 3.0 High Speed, USB 2.0 High Speed, Gigabit Ethernet, RS-232 Sample Speed With On-board Averaging: 1.1 to 9.7 ms per Scan Data Transfer Speed: 1.8 to 9.7 (USB), 5.2 to 9.7 (Gigabit Ethernet), 430 to 432 ms/Scan (RS-232) Dimensions: 185 x 161 x 185, 185 x 145 x 184, 175 x 110 x 44, 175 x 127 x 44.5, 175 x 165 x 85, 250 x 179 x 144 mm Applications: Fluorescence; Luminescence; Raman Spectroscopy; Low-Light Applications; DOAS

UV-NIR; 200-1160 nm; Resolution 0.05-20.0 nm; Sensitivity 160,000-470,000 Counts/µW per ms Integration Time; CMOS or CCD Linear Array Detector; Interface USB 3.0, Gigabit Ethernet, RS-232; 175x110x44-315x445x135 mm Discover the High-Performance, Flexible AvaSpec-ULS Spectrometer Step into the realm of advanced spectroscopy with the AvaSpec-ULS from Avantes. This spectrometer is available in two versions: the ULS2048CL with a 2k pixel detector and the ULS4096CL with a 4k pixel detector. The AvaSpec-ULS can be configured as an OEM unit optimized for integration, a bench-only unit optimized for customized software communication, or a rackmount version that allows stacking multiple spectrometers for simultaneous measurements. The AvaSpec-ULS is a masterpiece of precision and versatility, designed to meet the dynamic needs of both research and industry. Whether you are engaged in laboratory research, quality control, environmental science, or medical diagnostics, this spectrometer is tailored to your specific requirements. In combination with our latest AS-7010 electronics, the AvaSpec-ULS offers a versatile and powerful device with high-speed USB3.0 communication and a second communication port that provides Gigabit Ethernet for integration into your company network and long-distance communication. Options include a detector collection lens to enhance sensitivity in the 200-1100 nm range and an order-sorting filter to reduce second-order effects. Furthermore, the AvaSpec-ULS is available with a wide range of slit sizes, gratings, and fiber-optic entrance connectors to ensure maximum adaptability and compatibility with various experimental setups and applications. This flexibility allows users to customize their spectrometer to specific requirements, ensuring optimal performance and precision in every use case. EVO Series: The Future of Spectroscopy AvaSpec-ULS2048CL-EVO Another member of our EVO series, the AvaSpec-ULS2048CL-EVO, uses CMOS technology instead of the conventional CCD technology, making it ready for the next decade. The dominant position of CCD detectors in the spectrometer field is fading, and new technologies like CMOS have evolved to become suitable alternatives. The AvaSpec-ULS2048CL-EVO offers this latest technology, ensuring a spectrometer platform for the coming years. Combined with our latest AS-7010 electronics, the AvaSpec-ULS2048CL-EVO offers a versatile device with USB3.0 communication, which is ten times faster than USB2, and a second communication port that provides Gigabit Ethernet for integration into your company network and long-distance communication, all at an affordable price. Besides the high-speed communication options, the EVO series spectrometers also offer a fast microprocessor and 50 times more memory capacity, allowing you to store more spectra onboard and realize more functionality. Options include a detector collection lens to enhance sensitivity in the 200-1100 nm range and an order-sorting filter to reduce second-order effects. The AvaSpec-ULS2048CL-EVO is available with a wide range of slit sizes, gratings, and fiber-optic entrance connectors. AvaSpec-ULS4096CL-EVO The AvaSpec-ULS4096CL-EVO is a high-resolution spectrometer from our EVO series, using CMOS technology instead of conventional CCD technology. With 4096 pixels, these spectrometers are tailored for high-resolution applications like plasma measurements and LIBS (Laser-Induced Breakdown Spectroscopy). The AvaSpec-ULS4096CL-EVO offers the latest technology, ensuring a spectrometer platform for the coming years. Combined with our latest AS-7010 electronics, it offers a versatile device with USB3.0 communication, which is ten times faster than USB2, and a second communication port that provides Gigabit Ethernet for integration into your company network and long-distance communication at an affordable price. Besides the high-speed communication options, the EVO series also offers a fast microprocessor and 50 times more memory capacity, allowing you to store more spectra onboard and realize more functionality. Options include a detector collection lens to enhance sensitivity in the 200-1100 nm range and an order-sorting filter to reduce second-order effects. The AvaSpec-ULS4096CL-EVO is available with a wide range of slit sizes, gratings, and fiber-optic entrance connectors. It comes with AvaSoft-Basic software, a USB cable, and an extensive manual. Preconfigured Spectrometers For customers with urgent needs and general flexibility in their specifications, Avantes offers a variety of preconfigured spectrometers. These spectrometers are kept in stock, making them readily available and significantly decreasing shipping time. Out of the six available models, four are configured for measurements in the UV-VIS-NIR range (200-1100 nm), one for the VIS-NIR range (360-1100 nm), and one just for the visible range (360-880 nm). Several models are equipped with a replaceable slit (RS). All preconfigured spectrometers are available at discount pricing (as opposed to custom models) and include an upgrade to AvaSoft-Full. Each spectrometer comes with a USB cable and an extensive manual, so you will have everything you need to start your experiments. With the AvaSpec-ULS spectrometers, you get precision, versatility, and cutting-edge technology tailored to your specific requirements.   Key Features: Optical Bench: ULS Symmetrical Czerny-Turner, 75 mm Focal Length Available Gratings: 150 to 3,600 lines/mmm Available Slit Sizes: 10 to 500 µm Wavelength Range: 200 to 1160 nm Resolution: 0.05 to 20.0 nm, Depending on Configuration Stray Light: 0.04% to 1.0%, Depending on Grating Sensitivity: 160,000 to 470,000 Counts/µW per ms Integration Time Detector: CMOS Linear Image Sensor, CCD Linear Array 750 to 3648 Pixels Signal/Noise: 200:1 to 350:1 A/D Converter: 16 Bit, 1 to 6 MHz Integration Time: 9 µs to 10 min Interface: USB 3.0 High Speed, Gigabit Ethernet, RS-232 Sample Speed With On-board Averaging: 0.38 to 3.7 ms per Scan Data Transfer Speed: 0.38 to 3.7 (USB), 1.0 to 3.8 (Gigabit Ethernet) 430 to 750 ms/Scan (RS-232) Slit Set Connectors: SMA-905 or FC/PC Dimensions: 177 x 127 x 44,5, 175 x 110 x 44, 175 x 165 x 85, 315 x 235/445 x 135 mm Applications: Reflection and Transmission Measurements for Optics, Coatings and Color Measurement; Irradiance and Emission Measurements for Environmental Applications, Light Characterization and Optical Emission Measurement; High-speed Measurements for Process Control, LIBS or Laser and Pulsed Light Source Characterization; Absorbance Chemistry

UV-NIR; 200-1160 nm; Resolution 0.05-20.0 nm; Sensitivity 160,000-470,000 Counts/µW per ms Integration Time; CMOS or CCD Linear Array Detector; Interface USB 2.0, USB 3.0, Gigabit Ethernet, RS-232; 175x110x44-315x445x135 mm Avantes’ AvaSpec StarLine family of instruments is comprised of high-performance spectrometers which exceed the demands of most general spectroscopy applications. Providing excellent price-to-performance ratios, the AvaSpec StarLine series includes high-speed instruments for process control, high-resolution instruments for demanding applications like atomic emission measurements and versatile instruments for common applications such as irradiance and absorbance chemistry. The AvaSpec StarLine instruments are fully integrated with Avantes' modular platform, allowing them to function as both stand-alone and multi-channel instruments. These products are fully compatible with other AvaSpec instruments in the AvaSpec SensLine and AvaSpec NIRLine. The entire AvaSpec StarLine is available as an individual lab instrument, as well as an OEM module for integration into customers' existing systems. To learn more about all the available options and to find the perfect setup that matches your needs, please contact AMS Technologies to discuss your wishes with our sales engineers. The AvaSpec-ULS2048 with CCD sensor is the workhorse of Avantes’ spectrometer line-up. Used in many applications in the UV/VIS range, it is particularly useful in time-critical situations thanks to its exceptional response speed. Connection with your PC is done via USB2-connection, delivering a scan every 1.8 ms. A close cousin to the AvaSpec-ULS2048 but with almost four times larger pixels is the AvaSpec-ULS2048L. It gives you twice the signal-to-noise ratio and 40% less dark noise, providing enhanced sensitivity at an affordable price. With its 3,648-pixel CCD sensor, the AvaSpec-ULS3648 provides high resolution for demanding applications. Featuring an electronic shutter, it can support integration times as short as 10 µs, making it ideal for CW laser measurements, among others. The AvaSpec-FAST series of instruments is especially designed for high-speed acquisitions, such as pulsed light source and laser measurements. Up to 5,637 spectra can be stored at 0.20 ms per scan using Avantes' unique store-to-RAM functionality. The AvaSpec-FAST series is available in five different configurations with 350 to 1,650 active pixels. Avantes’ AvaSpec-ULS2048L-EVO spectrometer with CCD sensor features USB3.0 communication with 10 times higher speed compared to USB2 as well as a Gigabit Ethernet port for integration in your company network and possibility for long distance communication. AvaSpec-ULS2048CL-EVO and AvaSpec-ULS4096CL-EVO spectrometers are based on CMOS arrays instead of the conventional CCD technology and are able to measure wavelengths from 200 to 1100 nm with resolutions of 2,048 or 4,096 pixels respectively. These versatile devices include fast USB3.0 communication and a Gigabit Ethernet port. Sometimes a single channel spectrometer is not enough, for example when you want higher resolution, more precise measurements over a broad range or to perform several redundant measurements at the same time for process control purposes. The AvaSpec dual channel spectrometers are designed specifically for this purpose, and if you need even more channels, Avantes’ AvaSpec multi-channel spectrometers fulfil your every need. Each spectrometer can be configured independently – you can select the right option from Avantes’ range of detectors, choose different slits and gratings. Please contact AMS Technologies to configure the perfect solution for your application. Suited for various measurements in the complete UV/VIS/NIR range of 200 to 1700 nm, the AvaSpec-UV/VIS/NIR versatile broadband spectrometer comes in one package, no separate units necessary. The first channel of this dual spectrometer is based on Avantes’ AvaSpec-ULS2048L, the second channel on the Avaspec-NIR256-1.7 (uncooled version), both with replaceable slit option. For customers with urgent needs and general flexibility in their specifications, Avantes keeps a variety of preconfigured spectrometers in stock so they are readily available within a significantly decreased shipping time. Out of the seven available models, five are configured to be used for measurements in the UV-VIS-NIR range (200 to 1100 nm), one for the VIS-NIR range (360 to 1100 nm), and one just for the visible range (360 to 880 nm). All preconfigured spectrometers are available at discount pricing (as opposed to custom models) and include an upgrade to AvaSoft-Full.Looking for a more compact solution? Avantes offers a line of small preconfigured spectrometers from their AvaSpec CompactLine as well. Accessories for the AvaSpec StarLine series of spectrometers includes slit kits to fully utilize your AvaSpec StarLine series spectrometer with the replaceable slit option installed, available in SMA, SMA/FCPC and FC/PC versions, as well as a wide range of cables to connect your AvaSpec spectrometer to an AvaLight series light source or one of Avantes’ many accessories like fiber optic switches, AvaTrigger, etc. Key Features: Optical Bench: ULS Symmetrical Czerny-Turner, 75 mm Focal Length Available Gratings: 150 to 3,600 lines/mmm Available Slit Sizes: 10 to 500 µm Wavelength Range: 200 to 1160 nm Resolution: 0.05 to 20.0 nm, Depending on Configuration Stray Light: 0.04% to 1.0%, Depending on Grating Sensitivity: 160,000 to 470,000 Counts/µW per ms Integration Time Detector: CMOS Linear Image Sensor, CCD Linear Array 750 to 3648 Pixels Signal/Noise: 200:1 to 350:1 A/D Converter: 16 Bit, 1 to 6 MHz Integration Time: 9 µs to 10 min USB 3.0 High Speed, USB 2.0 High Speed, Gigabit Ethernet, RS-232 Sample Speed With On-board Averaging: 0.38 to 3.7 ms per Scan Data Transfer Speed: 0.38 to 3.7 (USB), 1.0 to 3.8 (Gigabit Ethernet) 430 to 750 ms/Scan (RS-232) Slit Set Connectors: SMA-905 or FC/PC Dimensions: 177 x 127 x 44,5, 175 x 110 x 44, 175 x 165 x 85, 315 x 235/445 x 135 mm Applications: Reflection and Transmission Measurements for Optics, Coatings and Color Measurement; Irradiance and Emission Measurements for Environmental Applications, Light Characterization and Optical Emission Measurement; High-speed Measurements for Process Control, LIBS or Laser and Pulsed Light Source Characterization; Absorbance Chemistry

Wavelength range 190-1100nm; Dynamic Range 4500; Dark Noise 15 cnts; Integration time < 9μs-30sec; Minimal Stray Light 0.1-1%; SNR 365:1-375:1; Operating Temperature Range 5-55 °C Introducing the NEXOS™, a cutting-edge photonics backbone spectrometer designed to support a wide array of applications across various industries. Manufactured using Avantes’ latest automation techniques, this device ensures exceptional inter-instrument reproducibility. Discover how this groundbreaking spectroscopy instrument can enhance your application! The NEXOS™ by Avantes is a lightweight yet powerful spectrometer, optimized for high-end performance in spectroscopy integration. It boasts high-speed performance with integration times as short as 9 μs, minimal stray light at just 0.1%, and an impressive signal-to-noise ratio of 375:1.Compatible with Avantes light sources, accessories, and AvaSoft software, the NEXOS™ allows users to tailor their setups to meet specific measurement needs. This versatile and robust spectrometer features USB2 communication, with additional communication protocols (e.g., RS232/SPI) available for Original Equipment Manufacturer (OEM) applications. It can be customized with six different slit sizes and over 15 types of gratings, with a replaceable slit option standard for Non-OEM. Ideal for OEM applications, the NEXOS™ can be integrated with our Software Development Kits (AvaSoft). Avantes’ automated manufacturing process enables the efficient and rapid production of high volumes of the NEXOS™ spectrometer, ensuring high accuracy and reproducibility. Product Variations: In addition to the USB-powered NEXOS™, we offer the NEXOS™-Link and NEXOS™-Bench Only. The Link version provides various communication protocols for OEM customers (RS232 or SPI), while the Bench Only version is optimized for easy integration with the customer’s own electronic board or Avantes’ AS7010 electronic board. Key features: Versatile and robust Broad range of applications Excellent inter-instrument reproducibility USB, Link, and Bench-Only versions available Applications: OEM spectroscopy

Wavelength range: 190-1100nm; Stray Light 0.1-1%; SNR 365:1-375:1; Dynamic Range 4500; Dark Noise 15cnts; Integration Time 9 µs – 30 seconds; Temperature Range 5-55 °C The VARIUS™ spectrometer, featuring patented technology and an enhanced optical bench design, surpasses its predecessors in performance. It ensures accuracy and reliability across various applications and integrates seamlessly with AvaSoft software and crosslink solutions for added versatility. Two Versions: The VARIUS™ spectrometer is available in both standard and industrial (OEM) versions. It offers a choice between a 2048 or 4096-pixel detector and supports high-speed data transfer via USB3 and Gigabit Ethernet. The OEM version features a robust steel housing with electromagnetic shielding, designed for easy integration into your device or system. With its versatile and flexible design, this spectrometer allows for the analysis of a wide range of samples and measurements, providing quick insights into your research or application. Measurement Flexibility: Enhance performance by replacing the slit with different sizes. The new magnetic connector cover system allows easy access for slit replacement and performance customization, enabling effortless adaptation to various measurement scenarios for optimal results. High Reproducibility: Avantes’ automated manufacturing process for the VARIUS™ spectrometer ensures the production of high volumes with exceptional efficiency, speed, and accuracy. This automation guarantees reproducibility, making each VARIUS™ spectrometer identical. This streamlined process allows us to deliver high-quality spectrometers faster than ever before. Product Compatibility: The new VARIUS™ spectrometer is compatible with Avantes light sources, accessories, and AvaSoft software, allowing users to customize setups to meet their measurement needs. Key features: Available in standard and OEM verions High-speed dNEata transfer Versatile and flexible design High reproducibility Applications: Wide range of spectroscopy applications
