FOBS-12N-111-8/125-PPP-1550-50/50-60-3A3A3A-1-1 Fiber WDM/ Combiners / Splitters and Couplers
REQUEST PRICING AND AVAILABILITY
- Get your individual quote.
- Technical compatibility review included.
- Volume discounts available.
No obligation. Direct access to our engineering team.
Product number:
C005035-6
Manufacturer:
OZ Optics
Downloads
Product information "FOBS-12N-111-8/125-PPP-1550-50/50-60-3A3A3A-1-1 Fiber WDM/ Combiners / Splitters and Couplers"
Fiber Optic Beamsplitter;1x2;50/50 %;1550 nm;Polarization Maintaining
Properties "FOBS-12N-111-8/125-PPP-1550-50/50-60-3A3A3A-1-1 Fiber WDM/ Combiners / Splitters and Couplers"
| Core/ Cladding Diameter (Splitter): | 8/125 µm |
|---|---|
| Input -Connector (Splitter): | FC/APC |
| Input Fiber: | Polarization Maintaining |
| Jacket Diameter (Splitter): | 900 micron OD hytrel jacket |
| Length (Splitter): | 1 m |
| Output 1 -Connector: | FC/APC |
| Output 1 -Fiber: | Polarization Maintaining |
| Output 2 -Connector: | FC/APC |
| Quantity Per Set: | 1.0 |
| Return Loss (Splitter): | 60 dB |
| Split: | 1x2 |
| Splitter Type: | Fiber Optic Beamsplitter |
| Splitter Wavelength: | 1550 nm |
| Splitting Ratio: | 50/50 % |
Manufacturer "OZ Optics"
Located in Canada's capital city of Ottawa and established in 1985, OZ Optics Ltd. is a leading worldwide supplier of fiberoptic products for existing and next-generation optical networks such as components and test equipment. Target markets include telecommunications, cable television, medical, military, industrial, aerospace, petrochemical and educational sectors. OZ Optics is ISO 9001:2000 and Telcordia certified.
