Product information "FC D-Shape Adapters"
FC/PC, FC/APC; Key Width 2.05 mm Type R (Narrow Key), 2.18 mm Type N (Wide Key); D-Shape; Sleeve Zirconia, Phosphor Bronze; Simplex; Fiber Type SM/MM/PM
Optoplast’s series of FC D-shape adapters connect any single mode, multi mode or polarization maintaining fiber cable terminated with industry-standard FC Connector Kits and minimize back reflections by bringing the fibers’ cores into physical contact. Equipped with standard phosphor bronze (multi mode), high-quality phosphor bronze (single mode) or zirconia mating sleeves (single mode), these high-quality manufactured adapters reliably align the cores of each terminated fiber, guaranteeing a very low insertion loss. After 500 connections the insertion loss variation stays below 0.10 dB.
While the PC version has a wide key (2.18 mm) accepting both wide and narrow key connectors, the APC version’s narrow key (2.05 mm) ensures very accurate angular orientation for single mode and polarization maintaining fibers. The light weight products are easy to handle and their round flange and D-shape threaded part allows for fast mounting the adapters to panels with D-shape opening in various applications and environments.
Key Features:
- Adapters/ Mating Sleeves to Align FC Connector Terminated Fiber Cables
- Compliant with NTT and EIA / TIA specifications
- Low Insertion Loss
- Compact and Lightweight
- Easy Panel Installation
- High Durability
- Precision Alignment Straight Split Sleeves
- Ready to Mount’ Packaging in 50 Unit Blister Trays
Applications: Telecommunications; Local Area Network (LAN); Fiber Optic Instrument Interface; Testing Optical Devices
