CC800-24 Cabinet Cooler - 55,2W Cooling Capacity - Heatpipe based

Cabinet Cooler; Compressor Based; 400 W @+26°C Cabinet, +35°C Ambient; 24 VDC; 13 A; Flush Mount; Temperature Stability ±0.05 K Key Features: Miniature Compressor-based Air Cooler for Cabinet Cooling Tasks up to 400 W Compact Dimensions and Low Weight Compared to Peltier-based & Other Compressor-based Coolers Easy to be Attached to Customer Cabinet IP65 Environmental Protection (Ambient Side) – For Operation in Harsh Environments 24 VDC Power Supply – Independent of Mains AC Voltage or Frequency Integrated Temperature Controller Speed-controlled Compressor – no Hysteresis, Stabilized Temperature to ±0.05 K PWM Speed-controlled Fan for Noise Reduction IoT Ready: Remote Operation, Monitoring and Service over Integrated Ethernet Interface AMS Technologies’ mAC-C-400-24 compact and rugged, compressor-based mini air cooler provides cabinet cooling capacities up to 400 W. In comparison to Peltier-based cabinet coolers, the highly efficient mAC-C-400-24 features significantly lower size and weight due to its miniature compressor and customized condenser/evaporator. A powerful fan moves the cabinet internal air at 130 m³/h. The internal air's temperature is maintained at the set value within ±0.05 K by an integrated circuit controlling the rotary compressor’s speed. The external fan is PWM speed controlled for noise reduction. Global Use: Its 24 VDC supply voltage allows the mAC-C-400-24 to operate from the cabinet’s 24 VDC voltage rail, with no need to care for the local mains voltage or frequency. IoT Ready: Access the mini air cooler’s system parameters from any location via the integrated Ethernet interface, also allowing remote control, service and even firmware update. Your customized air cooler: The mAC-C-400-24 cannot cover your requirements? AMS Technologies’ thermal management specialists are happy to develop a solution tailored to your needs – based on compressor or Peltier technology – and offer all services from development and proof-of concept to series production. Get in touch with us now to discuss your customized air cooler. Specifications: Cooling Capacity: 400 W @+26°C Tchilled cabinet air +35°C Tambient Temperature Stability: ±0.05 K External Working Temperature Range: +10°C to +50°C Internal Working Temperature Range: +15°C to +35°C Operating Voltage: 24 VDC Max. Operating Current: 13 A Max. Power Consumption: 310 W Refrigerant: R134a, 130 g (0.19 tequCO2) Dimensions: 310 x 157 x 475 mm Weight: 15 kg Orientation: Flush Mount, Side Wall or Door Environmental Protection Level, Enclosure Side: IP2X Environmental Protection Level, Ambient Side: IP65 Approvals: CE Applications: Cabinet Cooling; Cooling of Air inside Cabinets for Applications With up to 400 W Power Dissipation; Harsh Environments
