AAS-DM01A-20-20 Diamond Film

Polishing Film;ADS Film (NEXT, 20x20x10, 10 sheets)

All Necessary Tools Included; Special Version for PM Connectors Available; Sturdy Aluminium Case; Weight 7.3 kg OZ Optics’ comprehensive fiber optic termination kits include all of the tools necessary to make field terminations of fibers with commercially available connectors. The kits come in a sturdy, dent-proof aluminium case, providing easy transport with rugged protection. The total weight of the kits is 7.3 kg. The kits contain enough consumable supplies to process about 100 connectors. The consumable supplies may be ordered separately. A special version of the termination kit is available for polarization maintaining (PM) connectors. This kit includes special low-shrinkage epoxies to minimize stresses on the fibers. The epoxy is available as a separate item. The kits include the following tools: Five 230 mm by 330 mm, 5 µm Grit Polishing Film Five 230 mm by 330 mm, 1 µm Grit Polishing Film Ten 230 mm by 330 mm, 0.3 µm Grit Polishing Film 100X Microscope With a Connector Adapter Five Packs of Two-Component Epoxy Three Sizes of Buffer Tube Strippers Screwdriver With Four Bits Glass Polishing Plate Diamond Pen Scribe Index Matching Gel Polishing Disc T-Type Stripper Cotton Swabs Crimping Tool Epoxy Mixer & Pad Utility Knife Kim Wipes Scissors Tape Fiber Cleaner Tweezers Folding Knife Cable Stripper In addition, a number of accessories are available for the kit that may be ordered separately. A connector heater is available for curing the epoxy used in the terminating kit. The heater can handle 24 connectors at once and ensures even curing. A heat gun for curing epoxy and to shrink heat shrink tubing is also available. Key Features: All Necessary Tools Included to Make Field Terminations of Fibers With Connectors Special Version for Polarization Maintaining (PM) Connectors Available Various Additional Accessories Available Sturdy, Dent-proof Aluminium Case Weight: 7.3 kg Applications: Field Termination of Fibers With Commercially Available Fiber Optic Connectors

High-speed, Portable Polisher for Field Assembly; Connector/Ferrule Type SC, MU, FC, LC, MT, MTRJ, Custom; Radius of Curvature 10 to 25 mm; Apex Offset <50 µm; Return Loss >50 dB NTT Advanced Technology’s POP-311 series of high-speed portable polishers is suitable for installing optical connectors or extending optical fibers at field work site. Its cylinder jig allows for on-site polishing / re-polishing of MPO connectors and single fiber connectors. High polishing quality equivalent to that of factory use polishers can be achieved. The POP-311 high-speed portable polishers are able to polish connectors at very high velocity – up to 700 revolutions per minute. The POP-311 series is also suitable for re-polishing of MT connectors. When optical fiber connectors due to be laid are found to be damaged, on the spot repolishing makes them ready to be used. Also, LC-Duplex connectors can be simultaneously polished without dismantling. With only three to five processes, polishing MPO connectors and single fiber connectors can easily be done on location. For example, the polishing procedure from adhesive removal to advanced PC polish takes about 150 seconds (SC connector/terminal), while advanced PC polish by re-polishing takes only about 50 seconds (SC connector/terminal). Applicable connectors/ferrules are SC, MU, FC, LC, MT and MTRJ type optical connectors and glass ferrules. A broad range of attachments is available for the various different connector types. Since the attachments are the same as for the factory use ATP-3000 polishing machine, they can be used for a wide range applications such as MPO connectors and single fiber connectors (UPC/APC), and polishing of all types of capillaries and fibers. Widely accessible rechargeable nickel hydride battery (AA) or alkaline dry battery (AA) can be used as power supply. Key Features: Suitable for MT, MTRJ, SC, MU, FC and LC Connectors High Quality- Battery Operated High Speed Polishing Applications: Optical Connector Polishing (for re-polishing and new polishing processes)

Main Unit;POP311;AC power adapter (100-240V, 50-60Hz)

Polishing Film;AAS RC Film (1 um, A, 20x20, 100 sheets)

Adhesive;Optical Waveguide;Acrylate;5g

THT Through-Hole Technology;SWIR;1040 nm;100 mA
